Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 57
Product Description: Gasket
Category: STERN DRIVE / 1968 / 90 / DUE-15F 1968 / CARBURETOR GROUP
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
0379104 | 0379104 | Carburetor automatic choke assy | |
1 | 0379107 | Carburetor body plug assembly | |
2 | 0333695 | Screen, cover | This part replaces 0309949. |
3 | 0304201 | Lead shot | |
4 | 0306352 | .plug core | |
5 | 0305650 | Cotter pin | This part replaces 0306463. |
6 | 0125545 | Washer, hook, front | This part replaces 0552783. |
7 | 0308882 | Choke arm | |
8 | 0308893 | Screw | |
9 | 0305223 | Hinge | |
10 | 0309650 | Drive screw, hinge | |
11 | 0310116 | .spring, throttle shaft | |
12 | 0378757 | Cam follower assy | |
13 | 0308885 | Throttle valve | |
14 | 0313075 | . screw, choke valve | |
15 | 0378748 | Choke shaft arm assy | |
16 | 0382975 | .shaft arm throttle | |
17 | 0300803 | . washer, screw | |
18 | 0302812 | Screw, ground terminal | |
19 | 0308781 | .bushing, choke shaft, short | |
20 | 0308780 | .bushing, choke shaft, long | |
21 | 0308750 | Gasket | |
22 | 0308772 | Housing automatic choke | |
23 | 0302104 | .screw, choke housing | |
24 | 0308840 | .valve, choke | |
25 | 0203470 | Retaining ring, pawl | This part replaces 0202139. |
26 | 0308773 | Sleeve | |
27 | 0380652 | Retainer | |
28 | 0378747 | Austomatic choke assy | |
29 | 0310537 | Knob | |
30 | 0307466 | Scres, bowl to body | |
31 | 0380652 | Retainer | |
32 | 0303212 | Screw, cover | |
33 | 0307529 | "o" ring, cam follower | |
34 | 0308719 | Knob | |
35 | 0310354 | Roller | |
36 | 0307832 | Plug, screw | |
37 | 0303630 | Washer | |
38 | 0328543 | Orifice, high speed, 58d, 90, | This part replaces 0308977. |
39 | 0307466 | Scres, bowl to body | |
40 | 0379103 | Float bowl plug assy | |
41 | 0303405 | . .plug, core | |
42 | 0308976 | Nozzle | |
43 | 0302661 | Hinge pin, float | |
44 | 0378654 | Float float arm | |
45 | 0396521 | Float valve seat assy | This part replaces 0378895. |
46 | 0301996 | Gasket | |
47 | 0308508 | Gasket | |
48 | 0308718 | Link | |
49 | 0306373 | Cotter pin, reverse lock | |
50 | 0308764 | Friction spring | |
51 | 0308894 | Washer | |
52 | 0334913 | O ring | This part replaces 0303598. |
63 | 0303518 | Spring, needle valve | |
54 | 0310573 | Needle valve | |
55 | 0306407 | Locckwasher,cover latch | |
56 | 0379602 | Hose assembly | |
57 | 0308761 | Gasket | |
58 | 0308758 | Housing air intake | |
59 | 0309898 | Transfer | |
60 | 0319292 | Screw, clamp | This part replaces 0308762. |
61 | 0308763 | Screw long | |
62 | 0306358 | Flat washer, helm mounting | |
63 | 0308842 | Support screen | |
64 | 0308841 | Screen small mesh | |
65 | 0308846 | Cover | |
66 | 0312765 | Plate | |
67 | 0308691 | Screw | |
68 | 0308724 | Cap,trunnion anchor | |
69 | 0308721 | Spacer | |
70 | 0308723 | Gasket | |
71 | 0305234 | Bow washer | |
72 | 0303886 | Lockwasher | |
73 | 0308985 | Bushing | |
74 | 0378752 | Throttle control | |
75 | 0308986 | Retaining ring | |
76 | 0308987 | Washer | |
77 | 0329594 | Screw, cam follower | This part replaces 0303737. |
78 | 0308944 | Yoke | |
79 | 0383598 | Solenoid assembly | This part replaces 0379558. |
80 | 0310680 | . terminal | |
81 | 0310572 | ,housing, connector | |
82 | 0310774 | Spring | |
83 | 0310603 | Gasket | |
84 | 0308720 | Screw | |
85 | 0310602 | Base | |
86 | 0381192 | Leaf plate assembly | |
87 | 0327074 | Screw | This part replaces 0307129. |
88 | 0309427 | Gakset, drain valve | |
89 | 0379093 | Drain plate screen assembly | |
90 | 0302031 | Leaf plate | |
91 | 0304655 | Plate | |
92 | 0302032 | , drain valve cover | |
93 | 0303761 | Screw | |
94 | 0302033 | Cover | |
95 | 0308709 | Screw | |
96 | 0379678 | Plunger solenoid | |
97 | 0308728 | Screw | |
98 | 0310823 | Shield carburetor | |
99 | 0308760 | Compression nut | |
100 | 0306327 | Ball sleeve | |
101 | 0308884 | Tubing |
