Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 65
Product Description: Clamp, Hose, Valve To Manifold
Category: STERN DRIVE / 1970 / 155 / HUFM-69M 1970 / CRANKCASE GROUP 90 HP
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
1 | 2737E-6010-C | Cylinder block assembly | |
2 | 2737E-6055-C | Cylinder liner standard | |
2 | 2737E-6055-D | Cylinder liner .020" o.s. | |
3 | 87837-ES2 | Plug, oil gallery, hex socket | |
4 | 0311376 | Core plug, side | |
5 | 353052-ES | Plug, oil gallery, slotted | |
6 | 357966-S | Expansion plug shaft | |
7 | 2730E-6K30-A | Retainer, oil seal, rear | |
8 | 2730E-6344-A | Gasket, retainer | |
9 | 304664-S2 | Bolt, retainer to block | |
10 | 34806-S7/8 | Lockwasher | |
11 | 2731E-6675-B | Oil pan | |
12 | 2730E-6781-B | Gasket set, oil pan | |
13 | 2724E-6730-A | Plug, oil drain | |
14 | 2724E-6734-A | Gasket, drain plug | |
15 | 20308-S7/8 | Bolt,distributor mounting | |
16 | 111041-ES8 | Washer, pan screw | |
17 | 2730E-6615-A | Inlet tub assy. | |
18 | 2730E-6623-A | Screen, oil pick up | |
19 | 2730E-6K65-A | Tube, oil return | |
20 | 34806-S8 | Washer, water pump | |
21 | 2737E-6752-A | Gauge, oil level | |
22 | 105E-8509-B | Pulley, water pump | |
23 | E29-CE-1 | Packing, cover to pan | |
24 | 20424-S8 | Bolt, water pump | |
25 | 45504-S8 | Bolt, cover to block | |
26 | 0313889 | Plub,water passage | |
27 | 0384446 | Cover seal, timing chain | |
28 | 105E-6362-C | Seal, cover | |
29 | 105E-6600-A | Oil pump assy | |
30 | 105E-6608-A | Rotor shaft assemblly | |
31 | 105E-6551 | Gear, drive | |
32 | 72432-S | Pin, gear to shaft | |
33 | 87066-ES | O ring cover to body | |
34 | 105E-6616-B | Cover, oil pump | |
35 | 20344-S7/8 | Screw, cover | |
36 | 34825-S7 | Lockwasher | |
37 | 105E-6663-D | Plunger, relief valve | |
38 | 105E-6654 | Spring, plunger | |
39 | 105E-6653-B | Retainer, spring | |
40 | 105E-6659 | Gasket, pump | |
41 | 20386-ES2 | Bolt, pump to block | |
42 | 34806-S7/8 | Lockwasher | |
43 | 115827-ES8 | Bolt, filter to pump | |
44 | 116087-ES | Washer, pump bolt | |
45 | 113E-6714-A | Filter assembly | |
46 | 113E-6731-A | Filter element | |
47 | EIADKN-18688- | Gasket, filter | |
48 | 2730E-6723-A | Seal, oil pan, rear | |
49 | 0381765 | Lead assembly, ground | |
50 | 0306424 | Bolt, pump mounting | |
51 | 0306453 | Lockwasher, fuel pump | |
52 | 20504-S8 | Bolt, water pump | |
53 | 0314823 | Retainer, cable con | |
54 | 0384450 | Water pump assembly | |
55 | 0313892 | Seal, c case front cover from seal part 309044 cut to 16 1 4" | |
56 | 0338518 | O ring, bearing housing | This part replaces 0313893. |
57 | 0313683 | Dowel pin, eng. to adapter | |
58 | 0306396 | Lock washer, control to boat | |
59 | 0306419 | Screw | |
60 | 0379948 | Screw, retainer to adapter | |
61 | 0303699 | Screw | |
62 | 0306407 | Locckwasher,cover latch | |
63 | 0383656 | Breather condense assembly | |
64 | 0315067 | Hose, valve to manifold | |
65 | 0308913 | Clamp, hose, valve to manifold | |
66 | 0308335 | Clamp, coil | |
67 | 0383161 | Adapter housing stud assembly | |
68 | 0314616 | Stud | |
69 | 0309614 | Dowel | |
70 | 0314127 | Pilot, adapter | |
71 | 0312997 | Screw, adapter to engine | |
72 | 0306405 | Washer, c c stud nut | |
73 | 3852217 | Coil assy. ignition | This part replaces 0383444. |
74 | 0550757 | L'washer,coil term | |
75 | 0306556 | Nut, leaf screw | |
76 | 0307143 | Washer, solenoid | |
77 | 3852218 | Bracket, oil cooler | This part replaces 0383448. |
78 | 0306519 | Scr,coil clamp | |
79 | 0306450 | Screw | |
80 | 0306283 | Washer, starter spindle | |
81 | 0309192 | Rondelle | This part replaces 0120196. |
82 | 0312861 | Screw, cable ground | |
83 | 0307001 | L'washer, stud c'case | |
84 | 0586180 | Ensemble solénoïde | This part replaces 0383622. |
85 | 0311217 | Sleeve | |
86 | 0330112 | Clamp, solenoid | This part replaces 0311218. |
87 | 0120052 | . . lockwasher, solenoid screw | |
88 | 0306325 | . . lockwasher, solenoid screw | |
89 | 0303783 | Nut | |
90 | 0306555 | Screw | |
91 | 0981654 | Ballast resistor | This part replaces 0383433. |
92 | 0303311 | Scr,clamp,eng cable | |
93 | 0383381 | Lead assembly, starter to solenoid | |
94 | 0383382 | Lead assy., coil to res. | |
95 | 0309437 | Clip, drapeau | |
96 | 0204036 | 10 ring termial,12v | |
97 | 34805-S7/8 | Lockwasher, cover bolt | |
98 | 87786-S | Plug, block drain | |
99 | 353096-S | Plug, expansion | |
100 | 2733E-6A785-A | Separator assy. | |
101 | 378766-ES | Grommet | |
102 | 34805-S8 | Washer, water pump |
