EVINRUDE-JOHNSON 317181 Shifter, Cluch Dog

Write a Review
$159.99
SKU:
317181-OMC
Schematic Object Key:
42

EVINRUDE-JOHNSON 317181 Shifter, Cluch Dog

$159.99

Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.

EVINRUDE-JOHNSON 317181 Shifter, Cluch Dog

Schematic Object Key : 42

Product Description: Shifter, Cluch Dog

Category: EVINRUDE / 1971 / 100 / 100193C 1971 / GEARCASE

Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.

Parts List:

Key Part No. Product Name Additional_info
0384583 0384583 Gearcase assy., complete
1 0384581 Gearcase brg. assy
2 0384195 Bearing, pinion
3 0354731 O ring This part replaces 0314728.
4 0384584 . bearing hsg. seal assy
5 0321466 . oil retainer, driveshaft This part replaces 0313337.
6 0301250 Rondelle
7 0316534 . screw, hsg. to gearcase
8 0316482 Gaer, reverse
9 0385056 Oil pump assembley
10 0120052 . . lockwasher, solenoid screw
11 0307175 ,,screw ,housing
12 0314492 . screw, screen to valve hsg.
13 0314491 O ring
14 0315391 Cover
15 0383784 . screen valve housing
16 0315389 . piston, hydraulic shift
17 0384108 . valve housing assy
18 0315164 . . ball, valve shift
19 0315470 . . valve, seat
20 0202136 . . pin, cover to gearcase
21 0315163 . . valve, lever reverse
22 0315166 . . valve, lever neutral
23 0315482 . . rivet, valve bracket
24 0315403 Seal, valve housing
25 0315642 Band, seal valve housing
26 0314732 ,retainer plate, brg hsg
27 0329894 Screw This part replaces 0302510.
28 0397087 Bearing housing seal assy. This part replaces 0384523.
29 0382407 Bearing assy, forward gear
30 0379504 Propshaft bearing assembly
31 0330137 Seal This part replaces 0310600.
32 0316563 Screw
33 0317178 O ring
34 0314731 Rondelle de butée, engrenage de marche arrière
35 0314730 Nut, pinion to driveshaft
36 0315036 Pinion
36 0317169 Pinion
37 0387656 Butée, arbre d'entraînement This part replaces 0383248.
38 0327656 Rondelle de butée, arbre d'entraînement This part replaces 0314729.
39 0384424 Driveshaft assy
40 0383582 Gear bushing assembly
40 0385342 Gear and brushing assy. This part replaces 0385054.
41 0316028 Thrust waher, shifter dog fwd.
42 0317181 Shifter, cluch dog
43 0313448 Pin, clutch dog
44 0324369 Spring, clutch dog pin This part replaces 0313454.
45 0307551 Screw
46 0311598 Seal
47 0316484 Thrust washer, shifter
48 0315810 Spacer, impeller nut
49 0383878 Flame arrestor
50 0314877 . cover, solenoid
51 0314090 . retainer
52 0383781 . cable assembly
53 0379645 . . connector kit
54 0315072 Splice connector
55 0510817 Sleeve, shrink
56 0580780 . solenoid assy., upper
57 0580781 . solenoid assy., lower
58 0314406 . nut, shift solenoid
59 0315300 . lockscrew, shift rod casing
60 0510808 . plunger, upper, solenoid
61 0510809 . plunger, lower, solenoid
62 0510874 . shift rod, solenoid
63 0510811 . casting, shift rod
64 0510756 . spacer, shift solenoid
65 0315484 O ring
66 0382408 Thrust bearing
67 0314742 Shim bearing housing
68 0314745 Cale, 0,005" 0,12 mm
69 0382408 Thrust bearing
69 0385043 Thrust bearing assy.
70 0313446 "o" riing, brg. hsg
71 0314020 Sping, propeller shaft
72 0313445 Retaining ring
73 0315235 Retainer, clutch dog
74 0323466 . screen, water intake This part replaces 0314996.
75 0314126 Wave wahser, solenoid
76 0384546 Propeller shaft assy
77 0314876 Gasket, solenoid cover
78 0314731 Rondelle de butée, engrenage de marche arrière
78 0317165 Thrust washer, fwd
79 0338742 Compensateur de dérive This part replaces 0316981.
80 0323626 Screw This part replaces 0302873.
81 0330151 Cable clamp, filter This part replaces 0316386.
82 0329241 Washer This part replaces 0305981.
83 0383879 Cover seal
84 0321466 . oil retainer, driveshaft This part replaces 0313337.
85 0305760 Grommet
86 0326649 O ring This part replaces 0553127.
87 0308928 .key, impeller 5 inch longer parts
88 0306643 Screw
89 0313715 Screw, cap, hex hd, 7 16 14 x 1
90 0127084 Thrust bushing This part replaces 0384574.
91 0314081 Guide water tube
92 0314503 Nut, impeller
93 0314502 Cotter pin
94 0307708 Lock washer, mounting
95 0552898 Scr,grc to hsg,short
96 0306314 L'washer,scr,long
97 0313697 Scr,grc to hsg.long
98 0306470 Lock washer
99 0306503 Screw, adjustment rod
101 0385072 Impeller assembly
102 0314832 Grommet, water tube
103 0303806 Tubing
104 0315505 Impeller housing, gearcase
105 0314765 Guide, water tube
106 0382761 Propeller ,14 x 11
106 0382765 Propeller 13 x 19
106 0382766 Prop. 12 3 4 x 21 std
106A 0314188 Converging ring
106 0384142 Prop., 13 x 19 sst
106 0384703 Prop, 12 3 4 x 23 sst cupped
106 0384140 Prop., 13 3 4 x 21 2 bl. brnz.
