Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 81
Product Description: Trim Rod Assy.
Category: EVINRUDE / 1981 / 75 / E75ERCIM 1981 / POWER TILT & TRIM MODELS WITH "M" SUFFIX ONLY (EXPT 75 TRL)
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
0391037 | 0391037 | Hydraulic assy | |
1 | 0398110 | Manifold, power trim tilt | This part replaces 0390703. |
2 | 0321195 | . plub, manifold | |
3 | 0321164 | Plug | |
4 | 0323846 | Spring, piston | |
5 | 0325863 | Spring, relief valve | |
6 | 0324677 | O ring, valve core, upper | |
7 | 0325862 | Valve core, relief valve | |
8 | 0324678 | O ring, valve core, lower | |
9 | 0323848 | Piston, pump control | |
10 | 0391155 | Seat, valve core, relief valve | |
11 | 0326425 | O ring, value seat | |
12 | 0320780 | Screw, motor reservoir | |
13 | 0321163 | O ring, motor | |
14 | 0320980 | Sleeve, trim cylinder | |
15 | 0316602 | Screw, letdown plate | |
16 | 0300154 | Washer | |
17 | 0323408 | Plate, manifold | |
18 | 0321347 | . valve core, pilot valve | |
19 | 0321113 | . spring, pilot valve | |
20 | 0160084 | Ball | |
21 | 0983767 | Valve assy., relief valve | This part replaces 0323406. |
22 | 0202893 | "o" ring, drive shaft | |
23 | 0321345 | . valve seat, pilot valve | |
24 | 0321165 | Filter, reservoir | |
25 | 0320788 | End cap, trim cylinder | |
26 | 0321226 | Valve seat, filter | |
27 | 0319662 | O ring, end cap | |
28 | 0393988 | Motor and cable assy | This part replaces 0391264. |
29 | 0511657 | . . ring terminal | |
0392202 | 0392202 | . end cap brush assy. | |
0390986 | 0390986 | . end cap brush assy. | |
30 | 0321284 | Plug, reservoir | |
31 | 0307450 | "o" ring, large | |
32 | 0321350 | Filter, oil pump | |
33 | 0321716 | Ring, backup sleeve | |
34 | 0122757 | Seal, valve pump relief | |
35 | 0321357 | O ring | |
36 | 0321282 | Spring, relief valve | |
37 | 0122759 | Valve, pump relief | |
38 | 0390443 | Oil line assy., upper | |
39 | 0387397 | Oil line assy., lower | |
40 | 0360252 | Washer | This part replaces 0306311. |
0387248 | 0387248 | Cylinder assy., tilt | |
41 | 0387248 | Cylinder assy., tilt | This part replaces 0387584. |
0321117 | 0321117 | O ring, cam follower | |
42 | 0173594 | . . end head assy. | This part replaces 0387585. |
43 | 0174003 | 0 ring package | This part replaces 0387586. |
44 | 0387587 | . . piston head assy. | |
45 | 0321446 | . . . o ring | |
46 | 0387588 | . . piston rod assy. | |
0387248 | 0387248 | Cylinder assy., tilt | |
47 | 0387248 | Cylinder assy., tilt | This part replaces 0390005. |
48 | 0387248 | Cylinder assy., tilt | This part replaces 0390004. |
0390002 | 0390002 | Rod assy. complete | |
49 | 0390006 | Cap, o ring seal assy. | |
50 | 0390000 | Piston assy. | |
51 | 0390001 | Rod eyelet | |
52 | 0324385 | Washer, rod end | |
53 | 0324390 | Hex nut, rod end | |
54 | 0390007 | O ring package | |
55 | 0321246 | Bushing, shock lower | |
56 | 0321202 | Pivot pin, shock lower | |
57 | 0387517 | Valve seat, housing seal assy. | |
58 | 0304174 | "o" ring, tube adapter | |
59 | 0326649 | O ring | |
60 | 0387376 | Valve seat, housing seal | |
61 | 0326649 | O ring | |
62 | 0304174 | "o" ring, tube adapter | |
63 | 0391163 | Reservoir, trim tilt | |
64 | 0321239 | . piston, let down control | |
65 | 0122494 | Wiper, trim rod | |
66 | 0387990 | Manual release valve | |
67 | 0321362 | Retaining ring, manual release | |
68 | 0321542 | O ring, valve seat | |
69 | 0302290 | Washer | |
70 | 0321715 | Ring backup, end cap | |
71 | 0389836 | Oil pump assy. | |
72 | 0321219 | Screw, pump to manifold | |
73 | 0322174 | Drive coupling | |
74 | 0322175 | Ball, coupling | |
75 | 0321942 | Screw, oil pump to manifold, short | |
76 | 0323407 | . spring, relief valve | |
77 | 0321283 | O ring, trim cylinder | |
78 | 0983767 | Valve assy., relief valve | This part replaces 0389000. |
79 | 0326649 | O ring | |
80 | 0321117 | O ring, cam follower | |
81 | 0322724 | Trim rod assy. | |
82 | 0330809 | Seal, trim rod | This part replaces 0391622. |
83 | 0321209 | . . screw | |
84 | 0511465 | Connector, 3 pin recepticale | |
85 | 0582093 | Lead assy | This part replaces 0582092. |
86 | 0510151 | . . terminal | |
87 | 0511469 | Terminal, pin | |
88 | 0582878 | Indicator gauge assy. | This part replaces 0387758. |
89 | 0122552 | Ampoule | |
90 | 0122553 | Bulb socket | |
91 | 0320107 | Tie strap | |
92 | 0310981 | . screw, junction box mounting | |
93 | 0317000 | Cable, starter cable | |
0582192 | 0582192 | Junction box cover | |
94 | 0304489 | Screw, strap | |
95 | 0582191 | Colver transfer assy | |
96 | 0329182 | Screw, ground terminal | This part replaces 0327569. |
97 | 0315004 | . . jumper, terminal board | |
98 | 0321209 | . . screw | |
99 | 0512066 | Clamp | |
101 | 0581960 | . . cable assy., sending unit | |
102 | 0309433 | Borne | |
103 | 0510780 | 8 ring termianl | |
104 | 0511848 | . . . connector | |
104 | 0511848 | . . . connector | |
105 | 0582182 | Cable assy, battery | |
107 | 0510780 | 8 ring termianl | |
108 | 0511386 | . . . fuse | |
110 | 0511869 | . seal relay | |
111 | 0582186 | Connector lead | |
112 | 0511866 | Connector | |
113 | 0582187 | Cable assy, trim switch guage | |
115 | 0309433 | Borne | |
116 | 0309474 | . . . connector | |
117 | 0510780 | 8 ring termianl | |
118 | 0511865 | . terminal | |
119 | 0582188 | Cable assy tnt motor | |
120 | 0511865 | . terminal | |
121 | 0325699 | . connector | |
122 | 0511656 | Terminal | |
123 | 0511849 | . connector | |
124 | 0319603 | Screw, primer terminal | |
125 | 0511847 | Connector, sender | |
126 | 0511496 | Plug, seal |
