Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 8
Product Description: Screw, 3/4 In. X 3/8 X 24
Category: JOHNSON / 1997 / 105 / SJ105RWLP 1997 / STEERING HANDLE
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
1 | 0329879 | Guide | |
2 | 0325452 | Bague entre barre et support | |
3 | 0434930 | Steering handle assy. | |
4 | 0334960 | Pin, inner steering handle | |
5 | 0397001 | Handle, inner | |
6 | 0332089 | Retaining ring | |
7 | 0434366 | Cover, handle | |
8 | 0327254 | Screw, 3 4 in. x 3 8 x 24 | |
9 | 0329881 | Galet, hélice vers câble | |
10 | 0329880 | Goupille | |
11 | 0329063 | Seal | |
12 | 0339722 | Hélicoïdale, poignée tournante | |
13 | 0342803 | Sleeve, stop switch leads | |
14 | 0350989 | Screw | This part replaces 0325450. |
15 | 0315077 | Locknut, 3 8 24 ss | This part replaces 0325451. |
16 | 0436544 | Twist grip | |
17 | 5000031 | Throttle cable assy. | This part replaces 0437787. |
18 | 0174741 | Throttle frction control | |
19 | 0355221 | Steering arm bracket, tiller | This part replaces 0340779. |
20 | 0313607 | Lube fitting | |
21 | 0315077 | Locknut, 3 8 24 ss | |
22 | 0333374 | Shim, steering arm extension | |
23 | 0342933 | Plug, idle adjustment | |
24 | 0336481 | Screw, stop switch mount |
