Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 33
Product Description: Grommet, Throttle Cable
Category: EVINRUDE / 1990 / 25 / E25RWLESA 1990 / ENGINE COVER
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
| Key | Part No. | Product Name | Additional_info |
|---|---|---|---|
| 1 | 0283670 | Engine cover assy., ev | |
| 1 | 0432724 | Engine cover assy., jo | |
| 2 | 0322882 | Tilt handle | |
| 3 | 0330823 | Screw, duct to cover | |
| 4 | 0320400 | Hook, engine cover | |
| 5 | 0329635 | Hook, engine cover, rear | |
| 6 | 0554355 | Rivet | |
| 7 | 0316225 | Seal, engine cover | |
| 8 | 0211023 | Applique front | |
| 8 | 0334008 | Applique, engine cover, front | |
| 9 | 0334599 | Sound blanket, top | |
| 0334600 | 0334600 | Sound blanket, port | |
| 10 | 0334601 | Sound blanket, front | |
| 11 | 0334602 | Sound blanket, stbd | |
| 12 | 0329240 | Screw | |
| 13 | 0438793 | Connector, fuel | This part replaces 0397444. |
| 14 | 0325327 | Grommet, actuator cam | |
| 15 | 0320158 | Seal, housing to cover | |
| 16 | 0316354 | Engine cover support grommet | |
| 17 | 0304019 | Crommet, control shaft | |
| 19 | 0334761 | Grommet | |
| 20 | 0329217 | Screw, retainer | |
| 21 | 0302406 | Sleeve | |
| 22 | 0433392 | Engine cover, lower | |
| 23 | 0328703 | Washer, screw hook | |
| 24 | 0313607 | Lube fitting | |
| 25 | 0321319 | Lever, latch, lower engine cover | |
| 26 | 0553766 | Bow washer | |
| 27 | 0321863 | Washer, latch | |
| 28 | 0912127 | Screw, hook | |
| 29 | 0395910 | Handle shaft assy, latch | |
| 30 | 0331370 | Grommet | |
| 31 | 0334983 | Plug | |
| 32 | 0336255 | Grommet, shift rod | |
| 33 | 0335343 | Grommet, throttle cable | |
| 34 | 0329241 | Washer | |
| 35 | 0330996 | Seal, fuel connector | |
| 38 | 0325868 | Bracket, cove to exh. hsg., front | |
| 39 | 0908158 | Screw, anode | |
| 40 | 0328701 | Lockwasher, double ended bolt | |
| 41 | 0203622 | Washer | |
| 0211494 | 0211494 | Owner's manual, ev. | |
| 0211495 | 0211495 | Owner's manual, ev. | |
| 0433326 | 0433326 | Owner's manual, jo. | |
| 0433327 | 0433327 | Owner's manual, jo. | |
| 0283922 | 0283922 | Decal set, ev | |
| 0433646 | 0433646 | Decal set, jo |
