EVINRUDE-JOHNSON 335810 Cylinder Head, 115

Write a Review
$467.49
SKU:
335810
Schematic Object Key:
66

EVINRUDE-JOHNSON 335810 Cylinder Head, 115

$467.49

Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.

EVINRUDE-JOHNSON 335810 Cylinder Head, 115

Schematic Object Key : 66

Product Description: Cylinder Head, 115

Category: JOHNSON / 1998 / 80 / J115JTLECS 1998 / CYLINDER & CRANKCASE

Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.

Parts List:

Key Part No. Product Name Additional_info
1 0438922 Cylinder c'case assy., 90
1 0438921 Cylinder c'case assy.
2 0304178 Pin, dowel
3 0305070 Axe, carter moteur vers bloc
4 0336630 Goupille, cylindrique
5 0336166 Screw, c c to block
6 0335611 Screw, cyl to case, long
7 0335369 Fitting, drain
8 0335369 Fitting, drain
9 0437784 Ens. clapet anti retour
10 0437773 Check valve
11 HOSE, Cyl. block vent, 13 in. long
12 0306500 Screw, belt retainer
13 0437929 Bougie, champion, ql78yc
14 0333774 Attache, commande vers tringlerie de sens de marche
15 0585184 Interrupteur thermostatique, tribord
16 0511469 Terminal, pin
17 0513357 Connector, 1 pin receptacle
18 0329562 Cache, interrupteur
20 0338632 Thermostat cover
21 0340767 Fitting, lower drain
22 0324677 O ring, valve core, upper
23 0350357 Gasket, base plate This part replaces 0342291.
25 0331188 O ring
26 0335981 Seal, t stat cylinder head to c c
27 0328744 Screw, clamp 1 4 20 x .75
28 0330935 Bague, retenue de la tige du levier de sens de marche
29 0335020 Screw, bracket to block
30 0512741 Retainer, connector, 1 pin
31 HOSE, Drain system
32 0436853 Kit, rubber mount assy., upper
33 0344277 Screw, upper mount
36 0335523 O ring, cylinder head
37 0330933 Screw, reverse lock link
38 0343118 Liaison, levier vers bras de commande de sens de marche
39 0328725 Screw, cover to gearcase
40 0306012 Bow washer
41 0336136 Clamp
42 0311015 Bushing, pawl
43 0316195 Screw
44 0202026 Washer, rod
45 0436902 Levier de sens de marche
46 0328702 Washer
47 0349060 Cache, tourillon This part replaces 0335528.
48 0303492 Fitting, crankcase
49 0330941 Pin, retainer
50 5000470 Shift shaft arm assy This part replaces 0436822.
51 0349061 Tourillon This part replaces 0340761.
52 0435491 Thermostat
53 0338174 Ressort, thermostat
54 0328733 Rondelle, ressort
55 0333774 Attache, commande vers tringlerie de sens de marche
56 0437223 Grommet insert, exhaust relief
57 0328744 Screw, clamp 1 4 20 x .75
58 0335316 Joint, tige de commande de sens de marche
59 0436857 Bouchon gicleur, indicateur d'éjection
60 0585023 Interrupteur thermostatique, bâbord
61 0511469 Terminal, pin
62 0512746 Connecteur, 2 broches
63 0329562 Cache, interrupteur
65 0301967 O ring
66 0340950 Culasse, 90 cv
66 0335810 Cylinder head, 115
66 0342795 Cylinder head
67 0337478 Guide, fils du stator
68 0349557 Mount This part replaces 0328584.
69 0349556 Washer This part replaces 0329749.
71 0315189 Gasket, oil indicator
72 0341689 Filetr, overboard
73 0335521 Bague, levier de sens de marche vers bloc
74 0360761 Retainer, upper mount This part replaces 0340418.
75 0320107 Tie strap
76 HOSE, Tee to upper bearing vent,6 in. (152mm)
77 0328649 Screw, bowl to body
78 0335500 Joint, tribord
79 0335499 Joint d'étanchéité, bâbord
80 0330263 Screw, upper mount retention
81 0433817 Ensemble levier, tige de commande de sens de marche
82 0342916 Hose, exhaust grommet to block
83 0340734 Bushing, shift arm
84 0342923 Cover, cylinder block
85 0332135 Plug
86 0439559 Jeu de joints de bloc moteur
