Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 31
Product Description: Gasket, Cover Plate
Category: EVINRUDE / 1994 / 105 / E150JLERA 1994 / CARB. & INTAKE MANIFOLD 150 "V" OR "S" MODEL SUFFIX
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
1 | 0436845 | Throttle body assy, 150 stbd | |
1 | 0436846 | Throttle body assy, 150 port | |
1 | 0437317 | Throttle body ay., stbd., 150jpl | |
1 | 0437318 | Throttle body ay., port, 150jpl | |
1 | 0436847 | Throttle body assy, 150 stbd | |
1 | 0436848 | Throttle body assy, 150 port | |
2 | 0328714 | Screw, clip | |
3 | 0328765 | Attache | |
4 | 0340656 | Couvercle, poche d'étalonnage | |
5 | 0340657 | Gasket, cover | |
6 | 0340654 | Screw, cover | |
7 | 0328649 | Screw, bowl to body | |
8 | 0433000 | Chambre de flotteur | |
9 | 0317473 | High speed orifice, no. 30 | |
9 | 0323003 | Orifice, 25, 150jpl | |
9 | 0323149 | High speed orifice, no. 38 | |
10 | 0396522 | Ensemble soupape à flotteur | |
11 | 0336842 | Clip, spring | |
12 | 0343512 | Gasket, nozzle | This part replaces 0336405. |
13 | 0328714 | Screw, clip | |
14 | 0336366 | Attache, collecteur vers carter de papillon | |
15 | 0322907 | Orifice, intermediate no. 57d | |
15 | 0327769 | Orifice, high speed no. 70d | |
15 | 0327769 | Orifice, high speed no. 70d | |
16 | 0335070 | Gasket, float bowl | |
17 | 0335077 | Axe, flotteur | |
18 | 0433167 | Ensemble flotteur | |
19 | 0327116 | Screw, plug | |
20 | 0326164 | Screw, hinge pin | |
21 | 0340653 | Seal, carburetor body | |
22 | 0335363 | Crépine, carter de papillon | |
23 | 0433364 | Fuel manifold, port stbd | |
24 | 0335362 | Joint torique, tubulures carburant | |
25 | 0324643 | Screw | |
26 | 0328649 | Screw, bowl to body | |
27 | 0305739 | "o"ring,valve seat | |
28 | 0438995 | Carburetor body assy., 150, cx, vx, vc, vcx | This part replaces 0436849. |
28 | 0439755 | Carburetor body assy., 150jpl | This part replaces 0437319. |
28 | 0439756 | Carburetor body assy. | This part replaces 0436850. |
29 | 0335244 | Seal, air silencer | |
30 | 0341084 | Couvercle | |
31 | 0341085 | Gasket, cover plate | |
32 | 0315656 | Screw | |
33 | 0332576 | Ressort, soupape à pointeau | |
34 | 0342775 | Needle valve | This part replaces 0340883. |
35 | 0336226 | Gasket, manifold to block port | |
36 | 0336227 | Gasket, manifold to block stbd | |
37 | 0318165 | Dispositif de retenue, tringlerie de carburateur | |
38 | 0335242 | Bungie, long | |
39 | 0433521 | Balance tube | |
40 | 0433241 | Intake manifold assy, port | |
41 | 0433249 | Intake manifold assy, stbd | |
42 | 0435681 | Check valve assembly | |
43 | 0336639 | Crépine | |
44 | 0335121 | Fitting, primer | |
45 | 0335362 | Joint torique, tubulures carburant | |
46 | 0343269 | Link, port to stbd. carburetor | This part replaces 0335256. |
47 | 0389823 | Clapet | |
48 | 0323412 | Cale | |
49 | 0323601 | Butée de clapet | |
50 | 0327074 | Screw | |
51 | 0317739 | Leaf valve | |
52 | 0437372 | Air silencer assy | This part replaces 0336094. |
53 | 0335739 | Screw, conn. brkt. to mntg. brkt. | |
54 | 0432639 | Galet, contre came | |
55 | 0328735 | Washer, screw, ball joint | |
56 | 0335257 | Lever, linkage adjustment | |
57 | 0315656 | Screw | |
58 | 0328744 | Screw, clamp 1 4 20 x .75 | |
59 | SEAL, Cover | ||
60 | 0437372 | Air silencer assy | This part replaces 0336093. |
61 | 0333677 | Screw | |
62 | 0323626 | Screw | |
63 | 0335729 | Retainer, balance tube | |
64 | 0335403 | Seal, manifold to carb port | |
65 | 0335404 | Seal, manifold to carb stbd | |
66 | HOSE, Balance tube drain | ||
67 | 0324678 | O ring, valve core, lower | |
68 | 0303630 | Washer | |
69 | 0336821 | Gasket, air silencer | |
70 | 0438996 | Carburetor repair kit | This part replaces 0436852. |
