Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 46
Product Description: Strap. Lower Tilt
Category: JOHNSON / 2003 / 55 ML / J55ML / LOWER ENGINE COVER
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
| Key | Part No. | Product Name | Additional_info |
|---|---|---|---|
| 1 | 5005609 | Engine cover, lower | |
| 2 | 0332280 | Grommet | |
| 3 | 0331634 | Grommet | |
| 4 | 0318286 | Clamp | |
| 5 | 0909533 | Screw, adapter | |
| 6 | 0316354 | Engine cover support grommet | |
| 7 | 0304027 | Screw | |
| 8 | 0329518 | Grommet, esm mounting | |
| 12 | 0316002 | Support, front port | |
| 13 | 0328700 | Washer | |
| 14 | 0327196 | Support, front stbd | |
| 15 | 0302406 | Sleeve | |
| 16 | 0551793 | Screw | |
| 17 | 0329240 | Screw | |
| 18 | 0332169 | Seal, steering arm | |
| 19 | 0323474 | Hook, cover to housing | |
| 20 | 0323474 | Hook, cover to housing | |
| 21 | 0333706 | Screw, bearing housing to gearcase | This part replaces 0329239. |
| 22 | 0331249 | Washer, handle | |
| 23 | 0330151 | Cable clamp, filter | |
| 24 | 0551793 | Screw | |
| 25 | 0350911 | Grommet, plug | |
| 26 | 0328731 | Screw, battery cable clamp | |
| 27 | 0328456 | Clamp | |
| 28 | 0436201 | Cable | |
| 29 | 0329590 | Spacer, clamp | |
| 30 | 0337505 | Grommet, bracket | |
| 31 | 0337504 | Bracket, cyl. head to lower cover, starboard | |
| 32 | 0337503 | Bracket, cyl. head to lower cover, port | |
| 35 | 0320521 | Grommet | |
| 36 | 0349244 | Handle, lower cover | |
| 37 | 0349733 | Spacer, handle port stbd | |
| 38 | 0349963 | Spacer, handle, rear | |
| 39 | 0335223 | Screw, carburetor body, long | |
| 40 | 0378347 | Rope ay, starter | |
| 41 | 0123603 | Locknut, cover | |
| 42 | 0314494 | Bag emergency starter rope | |
| 43 | 0333677 | Screw | |
| 45 | 5004690 | Strap, rubber to covers | |
| 46 | 0350967 | Strap. lower tilt | |
| 47 | 5009240 | Valve, de watering | This part replaces 5004335. |
| 48 | 0349889 | Retaining ring, water valve | |
| 50 | 0306542 | Nut | |
| 51 | 5004332 | Decal set, complete |
