Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 21
Product Description: Hose, Upper C/C Pulse
Category: EVINRUDE / 2011 / 300 / DE300CZIIC / FUEL LIFT PUMP (3.4 L)
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
1 | 5007580 | Lift pump assembly, fuel upper | |
2 | *BRACKET, Fuel and Oil pump | ||
3 | 0124549 | Screw, fuel inlet | |
4 | 0353638 | Hose, pump to tee | |
5 | 0348839 | Clamp, 17 mm | |
6 | 0350981 | Hose, lower c c pulse | |
7 | 0346786 | Clamp | |
8 | 0350982 | Hose, upper c c pulse | |
9 | 0333710 | Screw, anchor bracket | |
10 | 0328703 | Washer, screw hook | |
11 | 0333040 | Isolator | |
12 | 0338558 | Entretoise, Ã collerette | |
13 | 0348839 | Clamp, 17 mm | |
14 | 0353541 | Tee, fuel hose | |
15 | 0772565 | Flexible | |
16 | 0348939 | Connector, fuel inlet | |
17 | 0353878 | Hose, pulse pump fuel outlet | |
18 | 5007581 | Lift pump assembly, fuel lower | |
19 | 0348839 | Clamp, 17 mm | |
20 | 0772565 | Flexible | |
21 | 0353640 | Hose, upper c c pulse | |
22 | 0346786 | Clamp | |
23 | 0353641 | Hose, lower c c pulse | |
24 | 0353639 | Hose, fuel outlet | |
25 | 0320107 | Tie strap | |
26 | 0345702 | Fitting, cooling hose |
