Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : –
Product Description: Blanket, Sound
Category: EVINRUDE / AF Models / 150 - (G2, 66° V6, 2.7 L) / C150HGXCAFB - (G2 66° V6, 2.7 L) / 01-2.2_ENGINE COVERS (PORT & STARBOARD)
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
1 | 0286113 | Cover assembly, port standard deep black | |
1 | 0286112 | Cover assembly, port standard bright white | |
1 | 0286114 | Cover assembly, port radical red | |
1 | 0286115 | Cover assembly, port orbital blue | |
1 | 0286116 | Cover assembly, port hyper silver | |
1 | 0286117 | Cover assembly, port ice blue | |
1 | 0286111 | Cover assembly, port mossy oak camo | |
1 | 0286158 | Cover assembly, port johnson white | |
1 | 0286079 | Cover assembly, port unpainted, does not include decals, or hardware | |
2 | 5009991 | Screw, retainer and clip kit kit services 6 quarter turn screws | |
3 | **SCREW, Quarter-turn | Not available individually | ||
4 | **RETAINER, Screw | Not available individually | ||
5 | **CLIP, Quarter-turn screw | Not available individually | ||
NS | 0358016 | Rivet | |
6 | 0358740 | Blanket, sound | |
7 | 0358972 | Speed nut, push on | |
8 | 5010764 | Frame assembly, port slate gray | |
8 | 5010400 | Frame assembly, port johnson white | |
9 | 0359650 | Seal | |
10 | 0359000 | Blanket, sound | |
11 | 0358387 | Blanket, sound | |
NS | 0360425 | Blanket, sound lower | |
12 | 0358972 | Speed nut, push on | |
13 | 5010767 | Cover, exhaust housing port slate gray | |
13 | 5010148 | Cover, exhaust housing port johnson white | |
– | 0359668 | Blanket, sound | |
14 | 0323229 | Screw, tilt handle, front inner | |
15 | 5010766 | Frame, front | |
16 | 0358385 | Blanket, sound | |
17 | 0358972 | Speed nut, push on | |
18 | 0358708 | Grommet, port | |
19 | 0358709 | Grommet, starboard | |
20 | 0286105 | Cover assembly, front standard deep black | |
20 | 0358611 | Cover assembly, front standard bright white | |
20 | 0358578 | Cover assembly, front radical red | |
20 | 0358612 | Cover assembly, front orbital blue | |
20 | 0358613 | Cover assembly, front hyper silver | |
20 | 0358614 | Cover assembly, front ice blue | |
20 | 0359867 | Cover assembly, front mossy oak camo | |
20 | 0359873 | Cover assembly, front johnson white | |
20 | 0361079 | Cover assembly, front unpainted, does not include decals, or hardware | |
21 | 0286105 | Cover assembly, front deep black | |
21 | 0286104 | Cover assembly, starboard bright white | |
21 | 0286106 | Cover assembly, starboard radical red | |
21 | 0286107 | Cover assembly, starboard orbital blue | |
21 | 0286108 | Cover assembly, starboard hyper silver | |
21 | 0286109 | Cover assembly, starboard ice blue | |
21 | 0286103 | Cover assembly, starboard mossy oak camo | |
21 | 0286157 | Cover assembly, starboard johnson white | |
21 | 0286078 | Cover assembly, starboard unpainted, does not include decals, or hardware | |
– | 5009991 | Screw, retainer and clip kit see ref 2. | |
22 | 0358741 | Blanket, sound | |
23 | 0358972 | Speed nut, push on | |
24 | 5010763 | Frame assembly, starboard slate gray | |
24 | 5010401 | Frame assembly, starboard johnson white | |
25 | 0359650 | Seal | |
26 | 0359001 | Blanket, sound | |
27 | 0358972 | Speed nut, push on | |
28 | 0358389 | Blanket, sound | |
NS | 0360426 | Blanket, sound lower | |
29 | 0586789 | Switch assembly, trim tilt | |
30 | 3011148 | Contact, tab | |
31 | 3011225 | Seal, wire | |
32 | 3011156 | Connector, 3 position | |
33 | 0334656 | Nut | |
34 | 5010768 | Cover, exhaust housing starboard slate gray | |
– | 0359669 | Blanket, sound | |
35 | 0323229 | Screw, tilt handle, front inner | |
36 | 5010762 | Cover assembly, rear frame | |
37 | 0217004 | Lens, logo 68 mm | This part replaces 0352505. |
38 | 0356286 | Retainer rear cover to exhaust grommet | |
39 | 0360810 | Seal, steering arm trac models | |
39 | 5010735 | Seal plug, steering arm dps, ihs idock models | |
– | 0361512 | Plug, steering arm seal use on dps and ihs models only | |
40 | 0362483 | Screw m5 x 20 | |
41 | 0362483 | Screw m5 x 20 | |
42 | 0362483 | Screw m5 x 20 | |
43 | 0362483 | Screw m5 x 20 | |
44 | 0362483 | Screw m5 x 20 | |
45 | 0362483 | Screw m5 x 20 | |
46 | 0362483 | Screw m5 x 20 | |
47 | 0362483 | Screw m5 x 20 | |
48 | 0359149 | Screw, m5 x 550 m5 x 55 | |
49 | 0360207 | Seal | |
50 | 0358257 | Insert, m5 x 0.8 oversized o.d. for replacement |
