Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 8
Product Description: Gasket, Plate To Engine
Category: STERN DRIVE / 1997 / 5.7 / 57FCPLKD 1997 / INTAKE MANIFOLD & FUEL PUMP - 2V & 4V MODELS
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
| Key | Part No. | Product Name | Additional_info |
|---|---|---|---|
| 1 | 3854268 | Manifold, intake | |
| 1 | 3854532 | Intake manifold | |
| 2 | 3850861 | Cover fuel filter assy | |
| 3 | 5011090 | Filter, fuel | This part replaces 0502906. |
| 4 | 3854269 | Gasket set, intake manifold | |
| 5 | 3856132 | Bolt, intake manifold, short | |
| 5 | 3856131 | Bolt, intake manifold, long | |
| 6 | 0312780 | Gasket, dist. to manifold | This part replaces 3852109. |
| 7 | 3852108 | Clamp, distributor | |
| 8 | 3852113 | Gasket, plate to engine | |
| 9 | 0312801 | Plate, fuel pump mounting | This part replaces 3852114. |
| 10 | 0311064 | Gasket, fuel pump | This part replaces 3852095. |
| 11 | 3852112 | Push rod, fuel pump | |
| 12 | 3852017 | Adapter, fuel line | |
| 13 | 0320107 | Tie strap | This part replaces 3852158. |
| 14 | 0303459 | Ecrew,exhaust cover,1 1 2"long | This part replaces 3852048. |
| 15 | 3852702 | Fitting, filter outlet | |
| 16 | 3853997 | Fuel line, filter to pump | |
| 17 | 0313022 | Locknut, double ended bolt | This part replaces 3852118. |
| 18 | 3852019 | Trunnion, s.a.e. cable | |
| 19 | 3856728 | Anchor bracket | |
| 20 | 3853428 | Screw, anchor bracket | |
| 21 | 3852621 | Bracket, fuel line clamp | |
| 22 | 0328724 | Screw | This part replaces 3852115. |
| 23 | 0511514 | Clamp, cable | This part replaces 3852231. |
| 24 | 3852075 | Plug, intake manifold | |
| 25 | 3855276 | Fuel pump assy. | |
| 26 | 3853169 | Sealer, manifold ends | |
| 27 | 0311375 | Nut | This part replaces 3852099. |
| 29 | 0909938 | Hose, fuel overflow | This part replaces 3854242. |
| 30 | 3853393 | Screw, bracket to manifold | |
| 31 | 0328724 | Screw | This part replaces 3852053. |
| 32 | 3852453 | Fitting, cover, return line | |
| 33 | 3850266 | Anchor block | |
| 34 | 3854104 | Fuel line, pump to carburetor | |
| 34 | 3857650 | Fuel pump, high pressure | This part replaces 3854280. |
| 35 | 3852013 | Elbow, filter inlet | |
| 37 | 0910068 | Tie strap, hoses | This part replaces 3852486. |
| 38 | 3853557 | Screw, brace to alterntr bracket | |
| 39 | 3853310 | Bracket, fuel filter | |
| 40 | 3852029 | Sender, water temperature | |
| 41 | 3853266 | Bolt, distributor | |
| 42 | 3853326 | Screw, bracket to engine | |
| 43 | 0310928 | Clamp, steering bracket | This part replaces 3852092. |
