Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 111
Product Description: Powerhead Gasket Set
Category: EVINRUDE / 1987 / 225 / E225CLCUB 1987 / CYLINDER & CRANKCASE
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
1 | 0395923 | Cylinder c'case assy. | |
2 | 0304178 | Pin, dowel | |
3 | 0314616 | Stud | |
4 | 0331095 | Pin, c c taper | |
5 | 0338653 | Stud, shift throttle levers | This part replaces 0320808. |
6 | 0326891 | Screw, cylinder to crankcase | |
7 | 0326890 | Screw, cylinder to crankcase | |
8 | 0320744 | Washer, stud | |
9 | 0322232 | Washer | |
10 | 0321598 | Crankcase fitting | |
11 | 0325604 | Fitting, boost port | |
12 | 0329892 | Screw, housing | |
13 | 0394892 | Check valve assy. | |
14 | 0772570 | Flexible, évent vers silencieux d'admission d'air , 2 1 4" 57 mm | This part replaces 0332219. |
15 | 0303806 | Tubing | |
16 | 0330145 | Cotter pin | |
17 | 0329740 | Arm, control arm | |
18 | 0329990 | Hose, overboard | |
19 | 0315094 | Bushing | |
20 | 0326644 | Lever, shift rod | |
21 | 0331211 | Gasket, cylinder head | |
22 | 0330366 | Hose, control valve to cover | |
23 | 0772570 | Flexible, évent vers silencieux d'admission d'air , 2 1 4" 57 mm | This part replaces 0332219. |
24 | 0331215 | Horse, elbow to tee | |
25 | 0909533 | Screw, adapter | |
26 | 0322323 | Screw | |
27 | 0502180 | Spark plug, champion ql77jc4 | This part replaces 0387633. |
28 | 0386686 | Switch temp | |
29 | 0325569 | Tee, primer solenoid hoses | |
30 | 0344472 | Gasket, rect. reg. to cyl. block | This part replaces 0330412. |
31 | 0330365 | Hose, oil cooler to aspirator | |
32 | 0329745 | Cover, thermostat stbd | |
33 | 0327590 | Pin, shift lever | |
34 | 0329562 | Cache, interrupteur | |
35 | 0330272 | Fitting | |
36 | 0396374 | Throttle lever, lower | |
37 | 0394407 | Control valve | |
38 | 0329787 | Seal | |
39 | 0330262 | Wiper | |
40 | 0330474 | 30 tee, water return hoses | |
40 | 0912234 | Tee, 30 | |
41 | 0328737 | Washer | |
42 | 0435009 | Pulse limiter | This part replaces 0174404. |
43 | 0328064 | Nut | |
44 | 0329744 | Cover, thermostat, port | |
45 | 0394408 | Diaphragm, thermostat cover | |
46 | 0392988 | Check valve | |
47 | 0398268 | Cylinder head | |
47 | 0398269 | Cylinder head | |
48 | 0330273 | Cap, thermostat | |
49 | 0320880 | Seat | |
50 | 0302288 | Bolt | |
51 | 0328695 | Clamp, engine cable | |
52 | 0312708 | Bushing | |
53 | 0302290 | Washer | |
54 | 0331894 | Elbow | |
55 | 0331933 | Hose, adapter to control valve | |
56 | 0202026 | Washer, rod | |
57 | HOSE, Drain system | ||
58 | 0320107 | Tie strap | |
59 | 0305650 | Cotter pin | |
60 | 0319253 | Fitting, c c lubrication | |
61 | 0308532 | Bague, levier de verrouillage | |
62 | 0308532 | Bague, levier de verrouillage | |
63 | 0315077 | Locknut, 3 8 24 ss | |
64 | 0331224 | Link, shift lever to shift arm | |
65 | 0330995 | Washer, override spring | |
66 | 0315077 | Locknut, 3 8 24 ss | |
67 | 0331635 | Screw, idle stop | |
68 | 0331737 | Link, shift arm | |
69 | 0396714 | Throttle lever, upper | |
70 | 0511618 | Retainer, connector, 2 pin | |
71 | 0333976 | Screw, actuator 1 4 20 x 2.5 | |
72 | 0328701 | Lockwasher, double ended bolt | |
73 | 0318660 | Bumper, screw, throttle stop | |
74 | 0328741 | Nut, input stud | |
75 | 0328702 | Washer | |
76 | 0330266 | Washer, trail lock lever | |
77 | 0328702 | Washer | |
78 | 0330266 | Washer, trail lock lever | |
79 | 0433481 | Shift arm | This part replaces 0393873. |
80 | 0396667 | Link assy., spark advance | |
81 | 0331879 | Screw | |
82 | 0326738 | Spring, link | |
83 | 0331863 | Rod, spark advance link | |
84 | 0331864 | Cap, spring housing | |
85 | 0328635 | Bushing, spring | |
86 | 0328712 | Ãcrou, montage instrument | |
87 | 0329770 | Pin, rod | |
88 | 0330145 | Cotter pin | |
89 | 0328636 | Pin, advance link | |
90 | 0434137 | Thermostat assy, | This part replaces 0394409. |
91 | 0434137 | Thermostat assy, | This part replaces 0329766. |
92 | 0394411 | Thermostat seat assy. | |
94 | 0396314 | Shift lever switch | |
95 | 0320107 | Tie strap | |
96 | 0331404 | Axe, interrupteur de démarrage au point mort | |
97 | 0396770 | Shift lever shaft | |
98 | 0583210 | Switch slider | |
99 | 0333749 | Ressort, interrupteur de démarrage au point mort | |
100 | 0331767 | Retainer | |
101 | 0317893 | Tie strap | |
102 | 0310928 | Clamp, steering bracket | |
103 | 0309040 | Clamp, exhaust cover | |
104 | 0319590 | Screw, plate 3 8 16 x .75 | |
106 | 0333595 | Bolt, double end | |
107 | 0328740 | Nut, throttle friction | |
109 | 0331216 | Hose, control valve to tee | |
110 | 0303715 | Washer, rivet | |
111 | 0398172 | Powerhead gasket set |
