Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 44
Product Description: Bracket, Starter Handle
Category: EVINRUDE / 1996 / 125 / SE125RWYV 1996 / REWIND STARTER
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
| Key | Part No. | Product Name | Additional_info |
|---|---|---|---|
| 0398235 | 0398235 | Rewind starter assy. | |
| 1 | 0333258 | Housing, starter | |
| 2 | 0331979 | Screw | |
| 3 | 0341063 | Bushing, pulley | |
| 4 | 0328741 | Nut, input stud | |
| 5 | ROPE | ||
| 6 | 0325431 | Spring, starter | |
| 7 | 0398237 | Pulley, starter | |
| 8 | 0326120 | Spring, pawl plate to housing | |
| 9 | 0398228 | Pawl, starter | |
| 10 | 0121266 | Glide pin, starter housing | |
| 11 | 0327768 | Screw, rope guide pulley | |
| 12 | 0333260 | Guide, rope | |
| 13 | 0325429 | Shield, housing spring | |
| 14 | 0326131 | Shield, pulley spring | |
| 15 | 0326132 | Spring, pawl plate return | |
| 16 | 0326119 | Retaining ring | |
| 17 | 0340817 | Washer | |
| 18 | 0432111 | Pawl plate | |
| 19 | 0334350 | Sleeve, heat shrink | |
| 20 | 0309515 | Washer, spring | |
| 21 | 0311015 | Bushing, pawl | |
| 22 | 0326964 | Spring washer, bushing to pawl | |
| 23 | 0331929 | Bumper, pawl plate | |
| 24 | 0308624 | O ring | |
| 25 | 0328700 | Washer | |
| 26 | 0301250 | Rondelle | This part replaces 0911009. |
| 27 | 0908511 | Screw | |
| 28 | 0326129 | Sleeve | |
| 29 | 0326130 | Grommet | |
| 30 | 0306861 | Screw | |
| 31 | 0328731 | Screw, battery cable clamp | |
| 32 | 0306470 | Lock washer | |
| 33 | 0306470 | Lock washer | |
| 34 | 0330276 | Lockout lever | |
| 35 | 0326128 | Spring | |
| 36 | 0328456 | Clamp | |
| 37 | 0329245 | Ratchet, flywheel | |
| 38 | 0398550 | Plate pivot pin | |
| 39 | 0326249 | Handle, starter | |
| 40 | 0304325 | Anchor, rope | |
| 41 | 0328703 | Washer, screw hook | |
| 42 | 0437040 | Lockout lever assy | |
| 43 | 0331515 | Grommet | |
| 44 | 0432648 | Bracket, starter handle | |
| 45 | 0326136 | Grommet | |
| 46 | 0331249 | Washer, handle | |
| 47 | 0327768 | Screw, rope guide pulley | |
| 48 | 0313022 | Locknut, double ended bolt | |
| 49 | 0328696 | Screen, ground lead | |
| 50 | 0327253 | Timing pointer | |
| 51 | 0308688 | Washer | |
| 53 | 0432645 | Cable assy., lockout | |
| 54 | 0330338 | Slide | |
| 55 | 0304027 | Screw | |
| 56 | 0341171 | Support, pulley | |
| 57 | 0908158 | Screw, anode | This part replaces 0339824. |
