Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 4
Product Description: Mounting Hardware Kit
Category: JOHNSON / 2001 / 65 / J65WELSIR Commercial, elec start, 20 in shaft 2001 / REMOTE CONTROL - SIDE MOUNT - KEY SWITCH
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
1 | 5006180 | Remote control, surface side mount | This part replaces 0176380. |
2 | 0390610 | Shift lever assy. | |
3 | 0393219 | Cam, shift lockout | |
4 | 0434059 | Mounting hardware kit | |
5 | 0320107 | Tie strap | |
7 | 0318321 | Washer, remote control to boat | |
8 | 0318349 | Nut, mounting screw | |
9 | 0336245 | Screw, single control, portside | |
10 | 0306396 | Lock washer, control to boat | |
12 | 0323776 | Clevis pin, shift throttle lever | |
13 | 0321888 | Roller, detent, shift thr. plate | |
14 | 0324524 | Screw, mounting bracket switch | |
15 | 0323764 | Bushing, cam, hub cover | |
16 | 0323769 | Retainer plate | |
17 | 0325780 | Spring washer, cam to housing | |
18 | 0176250 | Housing cover assy. | |
19 | 0336244 | Screw, access cover to housing | |
20 | 0176360 | Horn | |
21 | 0514679 | Borne, broche | |
22 | 0514696 | Connector, 2 pin receptacle | |
23 | 0514697 | Lock wedge, 2 pin | |
24 | 0323766 | Mounting plate, neutral start switch | |
25 | 0321966 | Spacer | |
26 | 0306643 | Screw | This part replaces 0324064. |
27 | 0332428 | Slide, neutral lock | |
28 | 0323775 | Screw, handle | |
29 | 0397272 | Shift throttle plate assy. | |
30 | 0323757 | Bushing, throttle lever | |
31 | 0318277 | Screw | |
32 | 0318322 | Attache câble | |
33 | 0318324 | Screw, cover mounting | |
34 | 0126896 | Screw, clamp | |
35 | 0323772 | Screw, plate | |
36 | 0323773 | Spring, slide return | |
37 | 0127152 | Index plate, neutral lock | |
38 | 0394032 | Throttle lever assy. | |
39 | 0391036 | Knob friction adj. screw assy. | |
40 | 0331050 | Latch, fast idle lever | |
41 | 0389265 | Switch assy., neutral | |
42 | 0176395 | Cable assy. | |
43 | 0126908 | Sleeve, socket | |
44 | 0514679 | Borne, broche | |
45 | 0514684 | Lock wedge, 6 pin | |
46 | 0514688 | Connector, 6 pin | |
47 | 0910446 | Terminal, socket | |
48 | 0336846 | Borne | |
49 | 0512136 | Tubing | |
50 | 0126943 | Grommet | |
51 | 0127188 | Applique | |
52 | 0127055 | Handle, remote control | |
53 | 0323765 | Wave washer, shift thr. hub | |
54 | 0323771 | Plate, slide control lever | |
55 | 0318625 | Spring, detent | |
56 | 0127227 | Latch, remote control box | |
57 | 0389267 | Friction adjustment lever | |
58 | 0325191 | Nut, friction lever | |
59 | 0318228 | Washer, fast idle lever | |
60 | 0318277 | Screw | |
61 | 0336241 | Knob, handle | |
62 | 0321889 | Shoe, detent, shift throttle plate | |
63 | 0322012 | Separator, levers | |
64 | 0318277 | Screw | |
65 | 0323749 | Bushing, shift throttle plate | |
66 | 0325779 | Bushing, fast idle lever | |
67 | 0325781 | Lever, shift lockout | |
68 | 0325790 | Spring, friction adjusting screw | |
73 | 0350143 | Applique | This part replaces 0336247. |
76 | 0336243 | Cover, handle | |
77 | 5005801 | Switch, key lanyard | This part replaces 0175974. |
78 | 0176288 | Lanyard assy. | |
79 | 0127274 | Nut | |
80 | 0176287 | Key set | |
80 | 0127279 | Key 70 | |
80 | 0127280 | Key 71 | |
80 | 0127281 | Key 72 | |
80 | 0127591 | Key 75 | |
80 | 0127592 | Key 76 | |
80 | 0127593 | Key 77 | |
80 | 0127595 | Key 79 | |
81 | 0127078 | Lever, fast idle | |
82 | 0331428 | Screw, fast idle lever | |
83 | 0331430 | Screw, latch | |
84 | 0331429 | Nut, fast idle lever | |
85 | 0330868 | Keeper plate | |
86 | 0306643 | Screw | This part replaces 0324064. |
87 | 0176097 | Lead assy., neutral start | |
88 | 0126908 | Sleeve, socket | |
89 | 0316198 | Heat shrink tubing | |
90 | 0336846 | Borne | |
91 | 0910446 | Terminal, socket | |
92 | 0390143 | Dual remote control installation | |
93 | 0318321 | Washer, remote control to boat | |
94 | 0318631 | Screw | |
95 | 0318837 | Stud | |
96 | 0321868 | Spacer | |
97 | 0325963 | Screw | |
98 | 0390795 | Space kit, remote control mounting |
