Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 31
Product Description: Anode
Category: EVINRUDE / 1998 / 70 / E70FTLECS 1998 / STERN & SWIVEL BRACKET
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
1 | 5030207 | Fitting, grease | |
2 | 5030821 | Bonding lead, exh. hsg. to bracket | |
3 | 5030822 | Lead swivel to hsg | |
4 | 5030848 | Bracket, swivel, jo. | |
4 | 5030849 | Bracket, swivel | |
5 | 5030851 | Bushing, tilt tube | |
6 | 5030852 | Bushing, steering | |
7 | 5030853 | Steering arm, jo. | |
7 | 5030854 | Steering arm | |
8 | 5030407 | Screw 5x8 | |
9 | 5030456 | Washer | |
10 | 5030459 | Washer | |
11 | 5030477 | Shim | |
12 | 5030527 | Plug | |
13 | 5030548 | Seal | |
14 | 5030572 | Circlip | |
15 | 5030841 | Tilt pin lever assy | |
16 | 5030842 | Lever, tilt lock port | |
17 | 5030843 | Bushing, tilt stop rod | |
18 | 5030844 | Cover, tilt lock lever | |
19 | 5030845 | Spring, tilt lock lever | |
20 | 5030846 | Link, tilt lock lever | |
21 | 5030847 | Bracket, tilt lock spring | |
22 | 5030429 | Washer | |
23 | 5030409 | Screw | |
24 | 5030417 | Nut | |
25 | 5030512 | Pin | |
26 | 5030597 | Spring | |
27 | 5030834 | Stern bracket, stbd., jo. | |
27 | 5030835 | Stern bracket, stbd | |
28 | 5030836 | Stern bracket, port, jo. | |
28 | 5030837 | Stern bracket, port | |
29 | 5034152 | Shaft, clamp bracket | This part replaces 5030838. |
30 | 5030839 | Cap, transom bolt | |
31 | 5030907 | Anode | |
32 | 5030391 | Bolt | |
33 | 5030385 | Bolt 12x100 | |
34 | 5030409 | Screw | |
35 | 5030418 | Nut | |
36 | 5030427 | Nut, tilt tube | |
37 | 5030436 | Washer | |
38 | 5030438 | Rondelle entretoise | |
39 | 5030462 | Washer, lock | |
40 | 5030135 | Clamp, rect reg lead | This part replaces 5030346. |
41 | 5030855 | Pin, tilt lock | |
42 | 5030388 | Bolt | |
43 | 5030057 | Washer | |
44 | 5030426 | Nut |
