Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 13
Product Description: Key
Category: EVINRUDE / 2001 / 25 / E25PL4SIC 4-Stroke, Elec. Start, TNT, 15 IN. shaft 2001 / STERN & SWIVEL BRACKET
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
1 | 5030207 | Fitting, grease | |
2 | 5031667 | Lead mount brkt to hsg | This part replaces 5032699. |
3 | 5032057 | Bracket, swivel 15" models only. | |
3 | 5032056 | Bracket, swivel 20" models only. | |
4 | 5032058 | Bush | |
5 | 5032064 | Bush, steering | |
6 | 5032352 | Plate, steering arm, upper | |
7 | 5032066 | Steering arm 15" models only. | |
7 | 5032065 | Steering arm 20" models only. | |
8 | 5030407 | Screw 5x8 | |
9 | 5031851 | Washer | |
10 | 5032353 | Shim, steering arm, 0.3mm | |
11 | 5030548 | Seal | |
12 | 5030572 | Circlip | |
13 | 5031907 | Key | |
14 | 5031491 | Bush, tilt lock lever | |
15 | 5031492 | Spring assy., tilt lock | |
16 | 5034248 | Lever, tilt lock stbd | This part replaces 5032054. |
17 | 5034249 | Lever, tilt lock port | This part replaces 5032055. |
18 | 5032069 | Bracket, tilt lock spring | |
19 | 5030035 | Bolt | |
20 | 5031249 | Pin | |
21 | 5032354 | Adjuster, steering | |
22 | 5031499 | Cache, dispositif de réglage de direction | |
23 | 5032355 | Bolt 8x27 | |
24 | 5031284 | Spring | |
25 | 5030344 | Washer | |
26 | 5032060 | Adjuster, steering rope rope electric models only. | |
27 | 5032061 | Plate, steering adjuster rope rope electric models only. | |
28 | 5032062 | Stud, steering lock rope rope electric models only. | |
29 | 5032063 | Plate, steering lock rope rope electric models only. | |
30 | 5031817 | Bolt 6x17 rope rope electric models only. | |
31 | 5031819 | Bolt 10x20.4 rope rope electric models only. | |
32 | 5032356 | Nut, shaft, steering lock rope rope electric models only. | |
33 | 5031832 | Washer rope rope electric models only. | |
34 | 5030063 | Washer rope rope electric models only. | |
35 | 5030429 | Washer rope rope electric models only. | |
36 | 5032292 | Lockwasher, plate, lock rope rope electric models only. | |
37 | 5031858 | Washer, wave | |
38 | 5031821 | Bolt 6x12 remote electric tnt models only. | |
39 | 5030527 | Plug remote electric tnt models only. | |
40 | 5032188 | Attachment, steering | |
41 | 5032177 | Bolt remote electric tnt models only. | |
42 | 5031611 | Lock washer remote electric tnt models only. | |
43 | 5032625 | Stern bracket, stbd | |
44 | 5032626 | Stern bracket, port | |
45 | 5032052 | Screw, clamp | |
46 | 5032053 | Handle, clamp | |
47 | 5030234 | Plate, clamp | |
48 | 5031865 | Pin | |
49 | 5034365 | Shaft, clamp bracket | This part replaces 5031487. |
50 | 5031489 | Cap, clamp bracket | |
51 | 5030839 | Cap, transom bolt | |
52 | 5035786 | Zinc set, protection | This part replaces 5030265. |
53 | 5030035 | Bolt | |
54 | 5030385 | Bolt 12x100 | |
55 | 5030418 | Nut | |
56 | 5030427 | Nut, tilt tube | |
57 | 5030436 | Washer | |
58 | 5030438 | Rondelle entretoise | |
59 | 5031846 | Washer | |
60 | 5030462 | Washer, lock | This part replaces 5031855. |
61 | 5031490 | Plug, clamp bracket remote electric tnt models only. | |
62 | 5032068 | Pin, tilit lock | |
63 | *5030054 | Nut | |
64 | 5030057 | Washer | |
65 | 5030438 | Rondelle entretoise | |
66 | 5032059 | Decal, release lever | |
67 | 5030840 | Seal | |
68 | 5032173 | Spacer | |
69 | 5032174 | Bolt | |
70 | 5032175 | Nut | |
71 | 5032176 | Washer | |
72 | 5030459 | Washer |
