Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 32
Product Description: Mount, Upper Thrust Rev
Category: JOHNSON / 2005 / 225 / BJ225X4SO / EXHAUST ADAPTER
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
1 | 5035130 | Holder, engine | |
2 | 5035023 | Seal, engine holder oil | |
3 | 5035054 | Plug, water | |
4 | 5035055 | Gasket, flush plug | |
5 | 5035131 | Seal, water return | |
6 | 5035138 | Gasket, engine holder | |
7 | 5035171 | Union, water indicator | |
8 | 5030515 | Pin | |
9 | 5030995 | Bolt, starter motor | |
10 | 5035132 | Cover, mount oil seal | |
11 | 5035133 | Gasket, mount oil seal cover | |
12 | 5035664 | Bolt, mount oil seal | |
13 | 5030515 | Pin | |
14 | 5034665 | Bolt 8x30 | |
15 | 5035134 | Cover, engine holder | |
16 | 5035135 | Gasket, engine holder cover | |
17 | 5034399 | Bolt 8x30 | |
18 | 5035136 | Cover, engine holder upper | |
19 | 5035137 | Seal, engine holder upper cov | |
20 | 5030995 | Bolt, starter motor | |
21 | 5031001 | Bolt | |
22 | 5033611 | Seal, oil | |
23 | 5035141 | Plate, upper mount | |
24 | 5035143 | Mount, upper new for 2005 | |
25 | 5034778 | Bolt, lower mount | |
26 | 5034792 | Nut, lower mount bolt | |
27 | 5034796 | Washer, upper mount bolt | |
28 | 5035144 | Cover, upper mount | |
29 | 5034783 | Bolt, upper mount | |
30 | 5034784 | Bolt, eng set no,2 l 50mm | |
31 | 5035140 | Stop, upper thrust | |
32 | 5035142 | Mount, upper thrust rev | |
33 | 5034785 | Bolt, eng set no,1 l 70mm | |
34 | 5034784 | Bolt, eng set no,2 l 50mm | |
35 | 5034786 | Bolt, eng set no,3 l 195mm | |
36 | 5034782 | Bolt, eng set no,4 l 115mm | |
37 | 5034781 | Bolt, cylinder head set 8x65 | |
38 | 5035268 | Washer, seal |
