EVINRUDE-JOHNSON 581532 Cable Assy, Tilt & Trim

Write a Review
$33.99
SKU:
581532
Schematic Object Key:
92

EVINRUDE-JOHNSON 581532 Cable Assy, Tilt & Trim

$33.99

Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.

EVINRUDE-JOHNSON 581532 Cable Assy, Tilt & Trim

Schematic Object Key : 92

Product Description: Cable Assy, Tilt & Trim

Category: EVINRUDE / 1977 / 200 / 200740C 1977 / POWER TILT AND TRIM

Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.

Parts List:

Key Part No. Product Name Additional_info
0387195 0387195 Hydraulic assy., power
1 0398110 Manifold, power trim tilt This part replaces 0387809.
2 0321195 . plub, manifold
4 0122494 Wiper, trim rod
5 0326649 O ring This part replaces 0553127.
6 0321117 O ring, cam follower
7 0322724 Trim rod assy.
8 0330809 Seal, trim rod This part replaces 0321580.
9 0320980 Sleeve, trim cylinder
10 0321283 O ring, trim cylinder
11 0391163 Reservoir, trim tilt This part replaces 0321031.
12 0320780 Screw, motor reservoir
13 0321163 O ring, motor
14 0321251 Sleeve, reservoir
15 0316602 Screw, letdown plate
16 0300154 Washer
17 PLATE,Manifold
18 0321347 . valve core, pilot valve
19 0321113 . spring, pilot valve
20 0160084 Ball
21 VALVE SEAT,Relief valve
22 0202893 "o" ring, drive shaft
23 0321345 . valve seat, pilot valve
24 0321165 Filter, reservoir
25 0320788 End cap, trim cylinder
26 0321226 Valve seat, filter
27 0319662 O ring, end cap
28 0387277 Motor and cable assy
29 0204038 . . . ring terminal
30 0321284 Plug, reservoir
31 0307450 "o" ring, large
32 0321350 Filter, oil pump
33 0321716 Ring, backup sleeve
34 0122757 Seal, valve pump relief
35 0321357 O ring
36 0321282 Spring, relief valve
37 0122759 Valve, pump relief
38 0390443 Oil line assy., upper This part replaces 0387396.
39 0387397 Oil line assy., lower
40 0360252 Washer This part replaces 0306311.
41 0387248 Cylinder assy., tilt
42 0387248 Cylinder assy., tilt This part replaces 0387584.
43 0173594 . . end head assy. This part replaces 0387585.
44 0174003 0 ring package This part replaces 0387586.
45 0387587 . . piston head assy.
46 0321446 . . . o ring
47 0387588 . . piston rod assy.
48 0321246 Bushing, shock lower
49 0321202 Pivot pin, shock lower
50 0387517 Valve seat, housing seal assy.
51 0304714 0 ring
52 0326649 O ring This part replaces 0553127.
53 0387376 Valve seat, housing seal
54 0326649 O ring This part replaces 0553127.
55 0304174 "o" ring, tube adapter
56 0321022 Piston, pump control
57 0321239 . piston, let down control
58 0303191 "o" ring, lever shaft
59 0387990 Manual release valve
60 0321362 Retaining ring, manual release
61 0321542 O ring, valve seat
62 0302290 Washer
63 0321715 Ring backup, end cap
64 0388065 Oil pump assy
65 0321219 Screw, pump to manifold
66 0322174 Drive coupling
67 0322175 Ball, coupling
68 0321942 Screw, oil pump to manifold, short
69 0323407 . spring, relief valve
70 0319984 Adaptateur, borne
71 0172899 . trim switch bezel assy.
72 0976443 Interrupteur, relevage assisté
73 0122849 . . bezel, trim switch
74 0310782 Écrou, interrupteur
75 0310781 Cache, interrupteur
76 0324001 Ramp
77 0315004 . . jumper, terminal board
78 0321209 . . screw
79 0306556 Nut, leaf screw
80 0120052 . . lockwasher, solenoid screw
81 0306325 . . lockwasher, solenoid screw
82 0321472 Écrou, câble solénoïde
83 0581528 . solenoid assy.
84 0581529 Lead assy, sol to term block
85 0204038 . . . ring terminal
86 0204053 Borne, anneau 0,312" 7,9 mm diamètre
87 0581530 . . lead assy., ground, solenoid to termina
88 0204038 . . . ring terminal
89 0204039 10 ring terminal
90 0511411 . . clamp
91 0581531 . . cable assy., battery
92 0581532 Cable assy, tilt trim
93 0204038 . . . ring terminal
94 0510780 8 ring termianl
95 0204039 10 ring terminal
96 0204036 10 ring termial,12v
97 0311742 Connecteur
98 0511656 Terminal This part replaces 0309435.
99 0581533 . . lead fuse assy.
100 0204053 Borne, anneau 0,312" 7,9 mm diamètre
101 0510780 8 ring termianl
102 0511386 . . . fuse
103 0581548 Cov trans incl. mtg. screws
104 0310981 . screw, junction box mounting
106 0319603 Screw, primer terminal
109 0122552 Ampoule
110 0122553 Bulb socket
111 0386681 . lead assy., trim gauge to horn
112 0510905 Grommet
113 0204036 10 ring termial,12v
114 0309437 Clip, drapeau
115 0320107 Tie strap
116 0321209 . . screw
117 0122481 Spacer, pivot
