Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 28
Product Description: Pulley
Category: STERN DRIVE / 1981 / 140 / 140SPHRCIF 1981 / ALTERNATOR GROUP DELCO REMY
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
| Key | Part No. | Product Name | Additional_info |
|---|---|---|---|
| 0982364 | 0982364 | Alternator assembly | |
| 1 | 0910599 | Regulater | |
| 2 | 0982870 | Rotor assembly purchase from gm dealer 1976163. | |
| 3 | 0982869 | Startor assy purchase from gm dealer 1971986. | |
| 4 | 0910605 | Frame, slip ring end | |
| 5 | 0982868 | . roller bearing, slip ring end | |
| 6 | 0910604 | Diode trio | |
| 7 | 0910603 | Rectifier bridge | |
| 8 | 0910602 | Nut, rectifier bridge | |
| 9 | 0982866 | Screw washer, rectifier bridge | |
| 10 | 0982867 | Brush holder brush assy | |
| 11 | 0982881 | Screw assy, brush holder, insulated | |
| 12 | 0910601 | Screw, brush holder, ground | |
| 13 | 0982865 | Terminal package, battery purchase from gm dealer 1846900. | |
| 14 | 0910606 | Washer, battery terminal neoprene | |
| 15 | 0910607 | Capacitor | |
| 16 | 0311717 | . bracket, capacitor | |
| 17 | 0982862 | Screw lockwasher, bracket lead | |
| 18 | 0910608 | Frame, drive end | |
| 19 | 0910609 | Ball bearing, drive end purchase locally at gm or delco remy dealer part number 1974861. | |
| 20 | 0910610 | Plate, ball bearing reatiner, drive end purchase locally at gm or delco remy dealer part number 1911263. | |
| 21 | 0910611 | Screw, ball bearing retainer plate purchase locally at gm or delco remy dealer part number 1965104. | |
| 22 | 0910612 | Collar, shaft, drive end purchase locally at gm or delco remy dealer part number 1959991. | |
| 23 | 0910613 | Nut, shaft, drive end | |
| 24 | 0910614 | Lockwaher, shaft, nut, drive end purchase locally at gm or delco remy dealer part number 1956978. | |
| 25 | 0910615 | Thru bolt purchase locally at gm or delco remy dealer part number 1956975. | |
| 26 | 0982861 | Screen assembly, drive end | |
| 27 | 0910616 | Fan | |
| 28 | 0910617 | Pulley | |
| 29 | 0982863 | Cover assembly, slip rind end | |
| 30 | 0982864 | Connector assembly | |
| 31 | 0512947 | Terminal, bullet | This part replaces 0910462. |
| 32 | 0302479 | Screw, starter mounting | This part replaces 0306416. |
| 33 | 3853411 | Brace, alternator | This part replaces 0910337. |
| 34 | 0306283 | Washer, starter spindle | |
| 35 | 0306325 | . . lockwasher, solenoid screw | |
| 36 | 0510981 | Tube, alternator leads | |
| 37 | 3852969 | Bushing, alternator to bracket | This part replaces 0910345. |
| 38 | 0201809 | Scew,starter to cylinder | |
| 39 | 0311407 | Lockwasher, lever to shaft | |
| 40 | 0200653 | Nut, stud alt. output | |
| 41 | 0318941 | Washer | |
| 42 | 0305496 | Locknut, alternator to bracket | |
| 43 | 0306450 | Screw | |
| 44 | 0306453 | Lockwasher, fuel pump | |
| 45 | 0306503 | Screw, adjustment rod | |
| 46 | 0306981 | Lockwasher, brace to pump | |
| 47 | 0306405 | Washer, c c stud nut | |
| 48 | 0306835 | Screw | |
| 49 | 3854068 | Bracket, alternator to engine | This part replaces 0910342. |
