Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 38
Product Description: Tappet, Valve, Standard
Category: STERN DRIVE / 1988 / 2.3 / 232AMRGDP 1988 / CYLINDER HEAD
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
Key | Part No. | Product Name | Additional_info |
---|---|---|---|
1 | 0986385 | Cylinder head | This part replaces 0985108. |
1 | 0986385 | Cylinder head | |
2 | 0914282 | Bushing, intake valve guide | |
3 | 3853108 | Plug, oil gallery | This part replaces 0914249. |
4 | 3852650 | Plug, core hole | This part replaces 0912932. |
5 | 0914501 | Seat insert, exhaust valve | |
6 | 0913142 | Valve, intake, standard | |
6 | 0914280 | Valve, intake, 0.015" o.s. | |
6 | 0914281 | Valve, intake, 0.030" o s | |
7 | 3853771 | Seal, exhaust | This part replaces 0913150. |
7 | 0914505 | Seal, exhaust, standard | |
7 | 3853031 | Seal, exhaust, 0.015 in. o.s. | This part replaces 0914283. |
7 | 0914508 | Seal, exhaust, 0.015" o.s. | |
7 | 0914284 | Seal, exhaust, 0.030" o.s. | |
7 | 0914509 | Seal, exhaust, 0.030" o.s. | |
7 | 3852670 | Seal, intake | This part replaces 0913151. |
7 | 0914504 | Seal, intake, standard | |
7 | 3853109 | Seal, intake, 0.015 in. o.s. | This part replaces 0914297. |
7 | 0914506 | Seal, intake, 0.015" o.s. | |
7 | 3853110 | Seal, intake, 0.030 in. o.s. | This part replaces 0914298. |
7 | 0914507 | Seal, intake, 0.030" o s | |
8 | 0913147 | Shim, valve spring, .030 | |
9 | 0913144 | Spring, valve | |
10 | 0913146 | Retainer, valve spring | |
11 | 0913148 | Key, valve spring retainer | |
12 | 0913149 | Arm, rocker | |
13 | 0986384 | Valve cover | This part replaces 0984880. |
13 | 0986384 | Valve cover | |
14 | 0912771 | Gasket, valve cover | |
15 | 0914277 | Bolt, oil pan | |
16 | 0913132 | Camshaft | |
17 | 3853108 | Plug, oil gallery | This part replaces 0914249. |
18 | 0984875 | Tensioner, timing belt | |
19 | 0914248 | Stud washer | |
20 | 0912758 | Spring, tensioner | |
21 | 0914256 | Bolt, tensioner spring | |
22 | 0914257 | Bolt, tensioner to head | |
23 | 0912759 | Sprocket | |
24 | 0913152 | Pin, sprocket | |
25 | 0914258 | Bolt, sprocket to camshaft | |
26 | 0914259 | Washer, sprocket | |
27 | 0912934 | Guide, timing belt | |
28 | 0913120 | Bearing, standard | |
28 | 0914250 | Bearing, 0.016" u.s. | |
29 | 0912761 | Belt, timing | |
30 | 0914260 | Plate | |
31 | 0914261 | Screw washer | |
32 | 0984877 | Seal, auxiliary shaft | |
33 | 0913119 | Bolt, cylinder head | |
34 | 0912764 | Gasket, cylinder head | |
35 | 0912763 | Plug, front cover | |
36 | 0913117 | Cover, outer | |
37 | 0914247 | Bolt, inner cover | |
38 | 0985313 | Tappet, valve, standard | |
38 | 0986307 | Tappet, valve, 0.020" o.s. | |
39 | 0912759 | Sprocket | |
40 | 0914259 | Washer, sprocket | |
41 | 0914294 | Bolt, sprocket | |
42 | 0914247 | Bolt, inner cover | |
43 | 0984646 | Cap, oil filler | |
44 | 0912938 | Spark plug, rs12yc | |
45 | 0913118 | Cover, inner | |
46 | 0912414 | Adapter, oil pressure switch | |
47 | 3853800 | Oil pressure sender | This part replaces 0982650. |
48 | 0913145 | Decal, timing | |
49 | 0913143 | Valve, exhaust, standard | |
49 | 0914278 | Valve, exhaust, 0.015" o.s. | |
49 | 0914279 | Valve, exhaust, 0.030" o.s. |
