Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 24
Product Description : Fan Ring Part No. 22347468 SN-2016108826
Product Category : TAD1640-42VE-C / Cooling System
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Other Components:
Key | Name | Part No. |
---|---|---|
1 | Charge Air Cooler | Part No. 22174556 |
1 | Charge Air Cooler | Part No. 23136793 |
2 | Radiator | Part No. 22174564 |
3 | Flange Screw | Part No. 996061 |
4 | Plate | Part No. 22347421 |
5 | Sealing Ring | Part No. 22347412 |
6 | Hose Clamp | Part No. 961672 |
7 | Hose | Part No. 22075129 |
8 | Radiator | Part No. 22174567 |
9 | O-Ring | Part No. 22347426 |
10 | Plug | Part No. 22347425 |
11 | Seal | Part No. 22343834 |
12 | Frame | Part No. 22174500 |
13 | Frame | Part No. 22174549 |
14 | Plate | Part No. 22155655 |
15 | Flange Screw | Part No. 984724 |
16 | Bracket | Part No. 22075131 |
17 | Frame | Part No. 22174498 |
18 | Bracket | Part No. 22272317 |
19 | Flange Screw | Part No. 984733 |
20 | Frame | Part No. 22075123 |
21 | Flange Screw | Part No. 984752 |
22 | Bracket | Part No. 22075190 |
23 | Cover | Part No. 22347467 |
23 | Cover | Part No. 23176225 |
24 | Fan Ring | Part No. 22347468 |
24 | Fan Ring | Part No. 78467816 |
25 | Flange Screw | Part No. 984733 |
26 | Bracket | Part No. 3808827 |
27 | Bracket | Part No. 3808825 |
28 | Flange Screw | Part No. 984734 |
29 | Seal | Part No. 22837691 |
Quick Overview
FAN RING
SKU : 22347468
PRE: VOL
BRAND: VOLVO
COMPANY: Volvo
