Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 1
Product Description : Fuel Pipe Part No. 22948032 SN11928080- 2 Gasket Part No. 969011 3 Hollow Screw Part No. 20405562
Product Category : TAD560VE / Fuel System
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Other Components:
Key | Name | Part No. |
---|---|---|
1 | Fuel Pipe | Part No. 21589969 |
1 | Tube | Part No. 21705466 |
1 | Fuel Pipe | Part No. 22948032 |
2 | Gasket | Part No. 969011 |
3 | Hollow Screw | Part No. 20405562 |
4 | Nipple | Part No. 941754 |
5 | Fuel Pipe | Part No. 21009492 |
6 | Gasket | Part No. 969011 |
7 | Hollow Screw | Part No. 25167 |
8 | Hollow Screw | Part No. 20405562 |
9 | Fuel Pipe | Part No. 20861113 |
9 | Fuel Pipe | Part No. 22395177 |
10 | Gasket | Part No. 969011 |
11 | Hollow Screw | Part No. 25167 |
12 | Hollow Screw | Part No. 20795864 |
13 | Gasket | Part No. 11996 |
14 | Retaining Plate | Part No. 20832800 |
15 | Retaining Plate | Part No. 20832847 |
16 | Flange Screw | Part No. 975197 |
17 | Clamp | Part No. 20450987 |
18 | Flange Screw | Part No. 984733 |
19 | Clamp | Part No. 20460045 |
20 | Flange Screw | Part No. 967949 |
21 | Bracket | Part No. 21086323 |
22 | Adapter | Part No. 20927443 |
