Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 40
Product Description : Fan Hub Part No. 3828711 For Thrust Fan., L=165mm
Product Category : TAD1630GE / Cooling System
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Other Components:
Key | Name | Part No. |
---|---|---|
1 | Radiator | Part No. 866089 |
1 | Radiator | Part No. 3829280 |
2 | Pressure Cap | Part No. 866095 |
3 | Gasket | Part No. 969011 |
4 | Gasket | Part No. 11994 |
5 | Plug | Part No. 960630 |
6 | Plug | Part No. 947660 |
7 | Hose | Part No. 192618 |
8 | Charge Air Cooler | Part No. 866090 |
9 | Fan Shroud | Part No. 3825747 |
9 | Fan Shroud | Part No. 3827830 |
10 | Flange Screw | Part No. 946173 |
11 | Flange Screw | Part No. 946441 |
12 | Flange Screw | Part No. 966862 |
13 | Bracket | Part No. 3826264 |
14 | Hexagon Screw | Part No. 970947 |
15 | Spring Washer | Part No. 941908 |
16 | Hexagon Nut | Part No. 971071 |
17 | Rubber Cushion | Part No. 849170 |
19 | Spring Washer | Part No. 940280 |
20 | Hexagon Nut | Part No. 955850 |
21 | Radiator Stay | Part No. 865207 |
22 | Hexagon Nut | Part No. 955793 |
23 | Spring Washer | Part No. 941912 |
24 | Washer | Part No. 191940 |
25 | Rubber Bushing | Part No. 866857 |
26 | Spacer Sleeve | Part No. 252202 |
27 | Bracket | Part No. 3826807 |
28 | Spacer Sleeve | Part No. 847239 |
29 | Flange Screw | Part No. 965183 |
30 | Hose | Part No. 865265 |
31 | Hose Clamp | Part No. 961673 |
32 | Hose | Part No. 865266 |
33 | Hose Clamp | Part No. 994560 |
34 | Elbow Nipple | Part No. 942649 |
35 | Radiator Protector | Part No. 865208 |
36 | Flange Screw | Part No. 947760 |
37 | Emblem | Part No. 846118 |
38 | Hose Clamp | Part No. 865575 |
39 | Cross Recessed Sunk Screw | Part No. 941651 |
40 | Fan Hub | Part No. 3828712 |
40 | Fan Hub | Part No. 3828711 |
41 | Stud | Part No. 969199 |
41 | Stud | Part No. 981590 |
42 | Flange Nut | Part No. 971095 |
43 | Fan | Part No. 848924 |
43 | Fan | Broad Leaf | Part No. 3825035 |
44 | Fan Guard | Part No. 865884 |
44 | Fan Guard | Part No. 3825490 |
45 | Flange Screw | Part No. 945444 |
45 | Flange Screw | Part No. 945444 |
45 | Flange Screw | Part No. 966807 |
46 | Spacer Washer | Part No. 946048 |
46 | Spacer Washer | Part No. 946048 |
46 | Washer | Part No. 191172 |
47 | Cable Tie | Part No. 948211 |
48 | Rubber Hose | Part No. 944386 |
49 | Rubber Hose | Part No. 943366 |
50 | Hose Clamp | Part No. 994556 |
51 | Charge Air Pipe | Part No. 865130 |
52 | Charge Air Hose | Part No. 865127 |
53 | Charge Air Hose | Part No. 865127 |
54 | Charge Air Pipe | Part No. 865131 |
55 | Washer | Part No. 190509 |
Quick Overview
FAN HUB
SKU : 3828711
PRE: VOL
BRAND: VOLVO
COMPANY: Volvo
