Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 80
Product Description : Decal Part No. 3851027 5.0FL
Product Category : SX-ST / Marine Propulsion
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Other Components:
Key | Name | Part No. |
---|---|---|
1 | Gear Housing | Part No. 3854378 |
2 | HSG & INSERT, GEAR | Part No. 3854384 |
3 | Insert | Part No. 3852541 |
4 | Insert | Part No. 3852567 |
5 | Insert | Part No. 3852515 |
6 | Insert | Part No. 3852513 |
7 | Ring | Thrust Plate | Part No. 3852516 |
8 | Shim | Upper Bearing, 0.002 In | Part No. 3852363 |
8 | Shim | Upper Bearing, 0.003 In | Part No. 3852364 |
8 | Shim | Upper Bearing, 0.004 In | Part No. 3852365 |
8 | Shim | Upper Bearing, 0.005 In | Part No. 3852366 |
8 | Shim | Upper Bearing, 0.010 In | Part No. 3852367 |
9 | Screw | Top Cover | Part No. 3850629 |
10 | Gasket | Top Cover | Part No. 3852317 |
11 | O-Ring | Oil Fill Plug | Part No. 3852045 |
12 | Indicator | Oil Indicator | Part No. 3852297 |
13 | Drive Gear Set | Pinion & Drive Gears | Part No. 3852396 |
13 | Kit | Part No. 21130692 |
16 | Bearing Housing | Pinion | Part No. 3852267 |
17 | Ring | Upper Bearing Support | Part No. 3852269 |
18 | Universal Joint | Part No. 3852384 |
19 | Yoke | Part No. 3850815 |
20 | Spacer | Part No. 3850813 |
21 | Yoke | Part No. 3850814 |
22 | Spider | Part No. 3850812 |
23 | Locking Clip | U-Joint | Part No. 3850757 |
24 | Washer | Pinion Gear | Part No. 3852310 |
25 | Seal | U Joint To Bearing Carrier | Part No. 3852272 |
26 | Shim | Bearing Carrier, 0.003 In | Part No. 3852355 |
26 | Adjusting Washer | Bearing Carrier, 0.004 In | Part No. 3852356 |
26 | Adjusting Washer | Bearing Carrier, 0.005 In | Part No. 3852357 |
26 | Adjusting Washer | Bearing Carrier, 0.010 In | Part No. 3852358 |
27 | O-Ring | Bearing Carrier | Part No. 3852308 |
28 | Flange Screw | Bearing Carrier | Part No. 3852454 |
29 | O-Ring | U Joint | Part No. 3852565 |
30 | Bearing | Drive Gear | Part No. 3852390 |
31 | Gasket | Water Passage | Part No. 3852279 |
32 | Locking Clip | Upper Driveshaft | Part No. 3852295 |
33 | Snap Ring | Spring | Part No. 3852299 |
34 | Sleeve | Pretension | Part No. 3852304 |
35 | Sliding Sleeve | Part No. 3852293 |
36 | Shaft | Upper | Part No. 3852292 |
37 | Ring | Bearing Retainer | Part No. 3852262 |
38 | Screw | Water Passage | Part No. 3852373 |
39 | Bearing | Drive Gear | Part No. 3852389 |
40 | Shim | Lower Bearing, 0.002 In | Part No. 3852368 |
40 | Shim | Lower Bearing, 0.003 In | Part No. 3852369 |
40 | Shim | Lower Bearing, 0.004 In | Part No. 3852370 |
40 | Shim | Lower Bearing, 0.005 In | Part No. 3852371 |
40 | Shim | Lower Bearing, 0.010 In | Part No. 3852372 |
41 | Shim | Upper Cover, 0.002 In | Part No. 3852368 |
41 | Shim | Upper Cover, 0.003 In | Part No. 3852369 |
41 | Shim | U Er Cover, 0.004 In | Part No. 3852370 |
41 | Shim | Upper Cover, 0.005 In | Part No. 3852371 |
41 | Shim | Upper Cover, 0.010 In | Part No. 3852372 |
42 | Nut | Upper Driveshaft, 0.000 In | Part No. 3852301 |
42 | Nut | Upper Driveshaft, 0.008 In | Part No. 3852302 |
42 | Nut | Upper Driveshaft, 0.016 In | Part No. 3852303 |
42 | Nut | Upper Driveshaft, 0.024 In | Part No. 3852375 |
43 | Spacer | Spring | Part No. 3852298 |
44 | Lock Ring | Seal | Part No. 3852307 |
45 | Screw | Pinion Gear Retainer | Part No. 3852309 |
46 | Bearing | Pinion To Inner Carrier | Part No. 3850852 |
47 | Bearing | Pinion To Outer Carrier | Part No. 3850853 |
48 | Spring | Clutch Cone To Shaft | Part No. 3852296 |
49 | Plug | Oil Plug | Part No. 3854539 |
50 | O-Ring | Oil Plug | Part No. 3855081 |
51 | Adjusting Washer | Thrust Plate, 0.015 In | Part No. 3852563 |
52 | Pressure Plate | Thrust, Port | Part No. 3852561 |
53 | Pressure Plate | Thrust, Starboard | Part No. 3852562 |
54 | Bearing Cover | Upper Gear Unit | Part No. 3854401 |
55 | Insert | Threaded, 5/16-18 | Part No. 3852513 |
56 | Strainer | Oil Sump | Part No. 3854021 |
57 | Shift Mechanism | Part No. 3852410 |
58 | Dog | Part No. 839646 |
59 | Spring | Shift Shoe | Part No. 814184 |
60 | O-Ring | Shift Actuator | Part No. 925093 |
61 | Bearing Housing | Part No. 839505 |
62 | Sealing Ring | Part No. 853868 |
63 | Spring Pin | Part No. 951924 |
64 | Clevis Pin | Part No. 942871 |
65 | Eccentric Piston | Part No. 897816 |
66 | Shim | Shift Shoe | Part No. 897871 |
67 | Hexagon Screw | Shift Shoe Stop | Part No. 897711 |
68 | Bracket | Shift | Part No. 3852276 |
69 | Cube | Cable To Bellcrank | Part No. 3852329 |
70 | Fork | Shift Link | Part No. 3852328 |
71 | Link | Bellcrank To Piston | Part No. 3852278 |
72 | Split Pin | Part No. 3854480 |
73 | Bar | Bellcrank | Part No. 3852277 |
74 | Clevis Pin | Shift Link To Piston | Part No. 3852330 |
75 | Screw | Shift Housing | Part No. 3852353 |
76 | Washer | Shift | Part No. 3852184 |
77 | Washer | Bellcrank | Part No. 3852193 |
78 | Washer | Shift Link | Part No. 3852083 |
79 | Plate | Waterpassage | Part No. 3852280 |
80 | Decal | Part No. 3851023 |
80 | Decal | Part No. 3851024 |
80 | Decal | Part No. 3851025 |
80 | Decal | Part No. 3851026 |
80 | Decal | Part No. 3851027 |
80 | Decal | Part No. 3851028 |
80 | Decal | Part No. 3851029 |
80 | Decal | Part No. 3851030 |
80 | Decal | Part No. 3851031 |
81 | Cover | Shift Mechanism | Part No. 3852418 |
82 | Flange Screw | Cover | Part No. 3852568 |
83 | Ring | Spacer | Part No. 3852294 |
84 | Split Pin | Shift Cable | Part No. 3854480 |
85 | Grommet | Part No. 3853424 |
86 | Nut | Drive To Pivot Housing | Part No. 3853329 |
87 | Bushing | Part No. 3853423 |
88 | Kit | Part No. 3850594 |
89 | Seal | Water Passage | Part No. 3852560 |
90 | Decal | Part No. 3850634 |
90 | Decal | Part No. 3850635 |
Quick Overview
DECAL
SKU : 3851027
PRE: VOL
BRAND: VOLVO
COMPANY: Volvo
