Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 14
Product Description : Radiator Bracket Part No. 847352
Product Category : TD1030VE / Cooling System
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Other Components:
Key | Name | Part No. |
---|---|---|
1 | Radiator | Part No. 1664500 |
2 | Anchorage | Part No. 1660904 |
3 | Hexagon Screw | 5/16uncx16mm | Part No. 955523 |
3 | Flange Screw | 5/16uncx16mm | Part No. 942402 |
4 | Spring Washer | Part No. 941907 |
5 | Radiator Stay | Part No. 1544860 |
6 | Rubber Bushing | Part No. 866857 |
7 | Spacer Sleeve | Part No. 252202 |
8 | Hexagon Nut | Part No. 955793 |
9 | Spring Washer | Part No. 941912 |
10 | Washer | Part No. 191940 |
11 | Rubber Cushion | Part No. 849170 |
12 | Hexagon Nut | Part No. 955850 |
13 | Spring Washer | Part No. 940280 |
14 | Radiator Bracket | Part No. 847352 |
15 | Hexagon Screw | Part No. 955295 |
16 | Spring Washer | Part No. 941907 |
17 | Fan Shroud | Part No. 475820 |
18 | Flange Screw | Part No. 946173 |
19 | Washer | Part No. 976944 |
20 | Flange Screw | Part No. 946544 |
21 | Washer | Part No. 976943 |
22 | Radiator Hose | Part No. 1544849 |
23 | Hose | Part No. 1082205 |
24 | Hose Clamp | Part No. 943480 |
25 | Fan Ring | Part No. 1544942 |
26 | Sealing Strip | Part No. 476612 |
27 | Hose Clamp | Part No. 1544650 |
28 | Flange Screw | Part No. 946173 |
29 | Washer | Part No. 976944 |
30 | Fan | Suction Type | Part No. 1674069 |
30 | Fan | Pusher Type | Part No. 3825017 |
30A | Fan | Temp. Controlled | Part No. 1660061 |
30B | Spacer | Part No. 1661040 |
30C | Flange Screw | Part No. 948217 |
31 | Flange Screw | Part No. 946671 |
32 | Hub | Part No. 1664828 |
32 | Fan Hub | Part No. 1675852 |
33 | Flange Screw | Part No. 947760 |
34 | Bracket | Part No. 1544859 |
35 | Expansion Tank | Part No. 3828638 |
36 | Bracket | Part No. 846884 |
36 | Bracket | Part No. 846885 |
37 | Hexagon Screw | Part No. 955294 |
38 | Spring Washer | Part No. 941907 |
39 | Hexagon Nut | Part No. 955782 |
40 | Pressure Cap | Part No. 866095 |
41 | Plug | Part No. 947660 |
42 | Gasket | Part No. 11994 |
43 | Hose | Part No. 192618 |
44 | T-Pipe | Part No. 948092 |
45 | Hose Clamp | Part No. 994556 |
46 | Rubber Hose | Radiator | Part No. 943366 |
47 | Rubber Hose | Intercooler | Part No. 943366 |
48 | Elbow Nipple | Part No. 942240 |
49 | Hose Clamp | Part No. 943471 |
50 | Hose | Part No. 952969 |
51 | Elbow Nipple | Part No. 942240 |
51 | Elbow Nipple | Part No. 942649 |
52 | Clamp | Part No. 949379 |
53 | Clamp | Part No. 18387 |
54 | Washer | Part No. 976943 |
55 | Spring Washer | Part No. 949607 |
56 | Hexagon Screw | Part No. 955269 |
Quick Overview
RADIATOR BRACKET
SKU : 847352
PRE: VOL
BRAND: VOLVO
COMPANY: Volvo
