Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 24
Product Description : Hose Part No. 860405 Heat Exchanger-After Cooler.
Product Category : KAD32P / Cooling System
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Other Components:
Key | Name | Part No. |
---|---|---|
1 | Heat Exchanger | Part No. 3586703 |
2 | Cap | Part No. 860755 |
3 | Sealing Strip | Part No. 860127 |
4 | O-Ring | Part No. 925027 |
5 | Gasket | Part No. 964106 |
6 | Hexagon Screw | Part No. 963567 |
7 | Shut-Off Cock | Part No. 949918 |
8 | Plug | Part No. 861551 |
9 | Bracket | Part No. 3581466 |
10 | Back-Up Ring | Part No. 838733 |
11 | Bracket | Part No. 3581468 |
12 | Stud | Part No. 953005 |
12 | Stud | Part No. 17378 |
13 | Stud | Part No. 953001 |
14 | Washer | Part No. 960142 |
15 | Flange Nut | Part No. 971095 |
16 | Stay | Part No. 860450 |
17 | Flange Screw | Part No. 946671 |
18 | Spacer | Part No. 3850090 |
19 | Flange Lock Nut | Part No. 948645 |
20 | Flange Screw | Part No. 965193 |
21 | Hose Clamp | Part No. 993964 |
22 | Hose | Part No. 3581470 |
23 | Hose Clamp | Part No. 994560 |
24 | Hose | Part No. 860405 |
25 | Hose Clamp | Part No. 994560 |
26 | Hose | Part No. 3581474 |
27 | Hose Clamp | Part No. 993964 |
28 | Hose | Part No. 3581469 |
29 | Spacer | Part No. 861554 |
30 | Stay | Part No. 3581467 |
31 | Flange Screw | Part No. 965226 |
32 | Flange Screw | Part No. 946440 |
33 | Flange Lock Nut | Part No. 948645 |
Quick Overview
HOSE
SKU : 860405
PRE: VOL
BRAND: VOLVO
COMPANY: Volvo
