Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 6
Product Description : Tube | Reservoir Part No. 873350
Product Category : DPX385XEFS / Steering
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Other Components:
Key | Name | Part No. |
---|---|---|
1 | Tank | Part No. 872137 |
2 | Hose Clamp | Part No. 961665 |
3 | Return Hose | Reservoir To Cooler | Part No. 872973 |
4 | Hose Clamp | Part No. 961666 |
5 | Suction Hose | Reservoir, Short | Part No. 3851506 |
6 | Tube | Reservoir | Part No. 873350 |
7 | T-Nipple | Multiple Engines | Part No. 872168 |
8 | Hose Clamp | Part No. 961665 |
9 | Suction Hose | Reservoir To Pump | Part No. 3851507 |
10 | V-Belt | Power Steering Pump | Part No. 3853368 |
11 | Flange Screw | Tension Brace, To Engine | Part No. 3853389 |
12 | Tensioner | Part No. 3851123 |
13 | Screw | Tension Brace | Part No. 1336961 |
14 | Flange Lock Nut | Pivot Screw, Power Steering Pump | Part No. 971099 |
15 | Spring Washer | Part No. 941909 |
16 | Screw | Adjustment, Steering Pump | Part No. 1346183 |
17 | Bracket | Pump To Engine, Rear | Part No. 856153 |
18 | Hexagon Screw | Rear Bracket To P/S Pump | Part No. 955295 |
19 | Bracket | Pump To Engine | Part No. 3851121 |
20 | Filler Cap | Reservoir | Part No. 1696361 |
21 | Screw | Bracket, P/S Pump To Engine | Part No. 3853558 |
22 | Flange Screw | Pivot, Power Steering Pump | Part No. 946473 |
23 | Bracket | Pump To Engine, Front | Part No. 856152 |
24 | Hexagon Screw | Front Bracket To P/S Pump | Part No. 955295 |
25 | Power Steering Pump | Part No. 1359649 |
26 | Pulley | Pump Assy, Power Steering | Part No. 1378643 |
27 | Spring Washer | Part No. 941907 |
28 | Hexagon Nut | Adjustment Screw | Part No. 955782 |
29 | Pressure Hose | Pressure | Part No. 872159 |
30 | Hose Clamp | Part No. 961664 |
31 | Attaching Clamp | Hoses To Front Mount | Part No. 3852490 |
32 | Clamp | Power Steering Hoses To Head | Part No. 3852837 |
33 | Screw | Clamp, Oil Cooler | Part No. 3852126 |
34 | Flange Screw | Oil Cooler Mounting | Part No. 3853266 |
35 | Clamp | Oil Cooler And Bracket Assy | Part No. 3852218 |
36 | Spacer | Oil Cooler, Power Steering | Part No. 3853236 |
37 | Nut | Clamp, Oil Cooler | Part No. 3852079 |
38 | Hose Clamp | Hose To Oil Cooler | Part No. 3852196 |
39 | Oil Cooler | Part No. 3851921 |
40 | Hose Clamp | Oil Cooler Water Hose | Part No. 3852602 |
41 | Hose | Vapor Separator To Oil Cooler | Part No. 3854849 |
42 | Return Hose | Oil Cooler | Part No. 872160 |
43 | Hose | P/S Cooler To Engine Cooler | Part No. 3854760 |
44 | Filter Insert | Reservoir | Part No. 349619 |
Quick Overview
TUBE
SKU : 873350
PRE: VOL
BRAND: VOLVO
COMPANY: Volvo
