YANMAR 127692-61700 Spring, Governor

Write a Review
$11.49
SKU:
127692-61700
Schematic Object Key:
49

YANMAR 127692-61700 Spring, Governor

$11.49

Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.

YANMAR 127692-61700 Spring, Governor

Schematic Object Key : 49

Product Description : SPRING, GOVERNOR 127692-61700

Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.

Other Components:

Ref Description Part No.
2 SEAL, AC0735-E00X9 122710-51080
3 LABEL 124610-51970
4 CASE, GOVERNOR 127695-61010
5 NUT, LOCK M8 26756-080002
6 NUT, LOCK M12 26777-120002
8 HOUSING, GOVERNOR 127695-61021
10 LINK 119000-61120
11 PIN, LINK 119000-61170
12 SPRING 127695-61190
13 LEVER ASSY, CONTROL 127695-61400
17 PIN, TAPER 3X22 22322-030220
18 BUSH 120323-61430
19 BUSH 127695-61430
20 BOLT, IDLE 129155-61460
21 PLUG, 20 129795-61470
22 SHAFT 119000-61490
23 LEVER ASSY, GOVERNOR 127692-61500
38 NUT, M6 26716-060002
39 SEAL, SC102004 120320-61540
40 BUSH 129595-61610
41 SHIM SET 119000-61630
47 LEVER, SETTING 127695-61631
48 SEAL, VC081404 148616-61650
49 SPRING, GOVERNOR 127692-61700
50 LINK 127495-61770
51 LINK 127495-61780
52 LINK 127495-61790
53 PIN, LINK 127695-61790
54 BUSH 127695-61840
55 SPRING 127695-61860
56 LEVER ASSY, STOP 127695-61870
60 LEVER 127695-61901
61 SPRING, RETURN 127695-61910
62 WASHER, 5 22117-050000
63 WASHER, 6 22117-060000
64 WASHER, 8 22137-080000
65 WASHER, SEAL 16 22190-160002
66 RING, E- 4 22272-000040
67 RING, E- 8 22272-000080
68 RING, E-10 22272-000100
69 PIN, PARALLEL M3X25 22312-030250
70 PIN, SPRING 3.0X16 22351-030016
71 PIN, SNAP 6 22372-060000
72 COTTER PIN 1.6X12 22411-160120
73 PIN, COTTER 1.2X12 22417-120120
74 PIN, B6X36 22492-060362
75 PLUG, 16 23887-160002
76 O-RING, 1AP12.0 24311-000120
77 O-RING, 1AS8.0 24341-000080
78 NUT, LOCK M6 26756-060002
79 GASKET 127695-61040
80 GASKET 119000-61052
81 COVER, GOVERNOR CASE 119187-61071
82 GASKET 127695-61071
83 TIN 114780-61090
84 WEIGHT ASSY,GOVERNOR 127695-61200
91 SLEEVE ASSY 127695-61300
92 SHIFTER 121850-61310
93 BEARING, THRUST 121850-61320
94 SHIFTER, T=4.0 127695-61330
95 SHIFTER, T=4.5 127695-61340
96 CIRCLIP 121850-61350
97 SLEEVE 128300-61350
98 NUT 121850-61380
99 SPRING 121850-61390
100 BOLT, IDLE 171353-61460
101 NUT, M6 119000-61470
102 BOLT, CONTROL 120323-61470
103 BOLT, LIMITER 127695-61470
104 NUT 127695-61480
105 ANGLEICH ASSY 127495-61550
108 SPRING, ANGLEICH 127495-61590
109 SHIM SET 127495-61700
116 RING, E- 4 22272-000040
117 NUT, LOCK 124616-61580
118 SHIM, T=1.0 127495-61710
119 NUT 152623-51560
120 NUT, CAP 129100-61930
121 NUT, M6 26716-060002
122 BOLT, M6X 35 PLATED 26106-060356
123 CASE 129595-61600
124 ROD, SLIDER 129595-61620
125 RING 127495-61660
126 BOLT, ADJUSTING 129595-61671
127 SPRING, DIAPHRAGM 127495-61680
128 DIAPHRAGM ASSY 129595-61681
129 PLUG, VALVE 144626-61690
130 O-RING 122710-51360
131 LINK 127495-61850
132 NUT, CAP 129100-61930
133 COVER, GOVERNOR CASE 127695-61951
134 GASKET 127695-61961
135 SUPPORT, WIRE 127881-61970
136 WASHER, SEAL 8 22190-080000
137 WASHER, SEAL 10 22190-100002
138 WASHER, SEAL 12 22190-120002
139 WASHER, SEAL 16 22190-160002
140 WASHER, SPRING 6 22217-060000
141 PIN, SPRING 5.0X10 22351-050010
142 WIRE, 1.0 120325-61100
143 PLUG, 10 23887-100002
144 PLUG, 16 23887-160002
145 BOLT, M6X 12 PLATED 26106-060122
146 BOLT, M6X 16 PLATED 26106-060162
147 BOLT, M6X 18 PLATED 26106-060182
148 BOLT, M6X 20 PLATED 26106-060202
149 BOLT, M6X 25 PLATED 26106-060252
150 BOLT, M6X 32 PLATED 26106-060322
151 BOLT, M8X 20 PLATED 26106-080202
152 BOLT, M6X 12 PLATED 26116-060126
153 BOLT, M6X 32 PLATED 26116-060326
154 IDLE 129907-61551
159 SPRING ASSY 127675-61590
159-1 SPRING ASSY 127675-61591
159-2 SPRING ASSY 127698-61590
160 PIECE 144626-61781
161 WASHER, 8 22117-080000
162 WASHER, SPRING 8 22217-080000
163 RING, E- 6 22272-000060
164 BOLT, M8X 14 PLATED 26106-080142
165 SUPPORT 127695-61490
165-1 SUPPORT, SPRING 127698-61490
166 SPRING 119173-61650
166-1 SPRING 119173-61651
167 BOLT 121850-61670
168 BOLT 121850-61660
