YANMAR XNH191302 Shelter

Write a Review
$831.29
SKU:
XNH191302
Schematic Object Key:
5

YANMAR XNH191302 Shelter

$831.29

Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.

YANMAR XNH191302 Shelter

Schematic Object Key : 5

Product Description : SHELTER

Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.

Other Components:

Ref Description Part No.
1 TURBINE ASSY 148806-18010
2 TURBINE ASSY 148806-18020
3 SHAFT, TURBINE XNH191551
4 BUSH, THRUST XN941806
5 SHELTER XNH191302
6 NUT XN181309
7 RING, SEAL XN781004
8 RING, SEAL XNH191305
9 RING, SEAL XNH191306
10 IMPELLER, BLOWER XNH195153
11 CASING, TURBINE XNH198352
12 LAGGING XN11198451
13 HEXAGON HEAD BOLT XN176003
14 RETAINER XNH196004
15 WASHER XNH196005
16 CASING XNH193110
17 CIRCLIP XN957104
18 PLATE XNH192501
19 BEARING, THRUST XNH193502
20 METAL, FLOATING XNH193501
21 SCREW M 4 XN947205
22 SCREW XN953304
23 CIRCLIP XN947204
24 PLATE, INSULATION XNH193108
25 CASING, BLOWER XNH194162
26 RETAINER XNH194105
27 BOLT XN907103
28 WASHER XN808506
29 SILENCER XNH199500
30 FILTER XN187809
31 PACKING XNH199503
32 BAND XN187812
33 GASKET, LIQUID XN193653
34 GASKET 148816-18400
34-1 GASKET 148816-18401
34-2 GASKET, TURBINE 148816-18402
34-3 GASKET, TURBINE 148816-18403
34-4 GASKET 148816-18404
35 PIPE 148817-18550
36 PIPE 148006-49220
37 CLAMP, 115 23000-115000
37-1 CLIP, HOSE 112 43730-552210
38 NUT, M10 26703-100002
39 RING, SEAL 125402-13550
40 TURBINE ASSY 148806-18011
41 TURBINE ASSY 148806-18021
42 SHAFT, TURBINE XNH291261
43 BUSH, THRUST XNH291243
44 SHELTER XNH291242
45 NUT XNH291244
46 SEAL RING XNN781004
47 RING, SEAL XNH191305
48 RING, SEAL XNH191306
49 IMPELLER, COMPRESSOR XNH295543
50 TURBINE HOUSING XNH198631
51 BOLT, M8 XNN137007
52 RETAINER XNN137423
53 BEARING HOUSING XNH293301
54 SNAP RING XNN957104
55 SEAL PLATE XNH292501
56 BEARING,THRUST XNH293602
57 METAL, FLOATING XNH193501
58 BOLT XNH193007
59 BOLT XNH193006
60 PLATE, INSULATION XNH293307
61 HOUSING, COMPRESSOR XNH194828
62 RETAINER XNH174404
63 BOLT XNH174307
64 SILENCER,SUC XNH199690
65 FILTER XNH199688
66 BAND XNH199708
