EVINRUDE-JOHNSON 335420 Bushing, Thrust

Write a Review
$37.49
SKU:
335420
Schematic Object Key:
65

EVINRUDE-JOHNSON 335420 Bushing, Thrust

$37.49

Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.

EVINRUDE-JOHNSON 335420 Bushing, Thrust

Schematic Object Key : 65

Product Description: Bushing, Thrust

Category: JOHNSON / 1995 / 25 / J25RWEOS 1995 / GEARCASE - S25RP

Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.

Parts List:

Key Part No. Product Name Additional_info
0434763 0434763 Gearcase assy, less driveshaft
1 5008160 Bearing housing seal This part replaces 0433428.
2 0321453 Seal, propeller shaft
3 0437288 Bearing assembly, propeller shaft
4 0328311 Cradle, clutch dog
5 0319743 Screw, propeller shaft bearing housing
6 0332584 Washer, seal ring
7 0327655 Gear, reverse
8 0439143 Propeller shaft This part replaces 0390268.
9 0327070 Spring, detent propeller shaft
10 0316506 Ball, detent
11 0337020 Shifter, clutch dog
12 0390023 Yoke connector assy
13 0308376 Pivot pin, shift lever
14 0332584 Washer, seal ring
15 0386186 Roller bearing, forward gear
16 0328313 Gear, pinion, driveshaft
17 0307551 Screw
18 0333572 O ring
19 0303049 Cotter pin
20 0434030 Gearcase
21 0322018 Housing, bearing
22 0386473 Bearing assembly
23 0321928 Retainer, oil, , lower
24 0332261 Seal, driveshaft upper
25 0320173 Stud
26 0326361 Bushing, shift rod lower
27 0325539 Screw, sceen to gearcase
28 0321738 Washer, seal, shift rod
29 0437288 Bearing assembly, propeller shaft
30 0336206 Screen, intake
31 0303347 "o" ring, lower bearing
32 0330441 Thrust washer, lower
33 0327716 Thrust washer, upper
34 0301877 O ring shift rod
35 0388027 Thrust bearing, pinion
36 0329217 Screw, retainer
37 5008161 Trim tab assy This part replaces 0336203.
38 5007582 Anode kit This part replaces 0434029.
39 0333677 Screw
40 0304454 Lock washer
41 0319684 Thrust washer
42 0337019 Lever, shifter
43 0392475 Gear bushing assy., forward
44 0302504 Pin, connector, shift rod
45 0319635 Bushing, reverse gear
46 0319747 Retaiining ring
47 0319746 Retainer plate, housing
48 0338518 O ring, bearing housing
49 0331465 Nut, shift rod connector
50 0341635 Driveshaft This part replaces 0328316.
51 0395289 Impeller key assy
52 0344470 Key, impeller This part replaces 0330619.
53 0301250 Rondelle
54 0306422 Nut
55 0328725 Screw, cover to gearcase
56 0393632 Impeller housing
57 0328754 Bushing, impeller housing
58 0319785 Bushing
59 0325537 Gasket, plate to gearcase
60 0328753 Seal, impeller housing to plate
61 0360633 Cup, impeller housing This part replaces 0328773.
61 0360633 Cup, impeller housing This part replaces 0328751.
62 0319891 Nut
63 0320785 Cotter pin
64 0326692 Spacer, impeller housing
65 0335420 Bushing, thrust
66 0325624 Connector, shift rod
67 0387320 Propeller 11 1 4 x 7 al
67 0391064 Propeller 10 17 al.
67 0765049 Propeller This part replaces 0386637.
67 0778863 Propeller This part replaces 0175191.
67 0765048 Propeller, aluminum, 3 x 11 in. x 9 p This part replaces 0386317.
67 0390728 Propeller 10 1 2 x 11 sst
67 0390727 Propeller 11 9 sst
67 0390380 Propeller 10 15 al
67 0390729 Propeller 10 13 sst
67 0390730 Propeller 10 15 sst
67 0390731 Propelleer 10 x 17 sst
68 0332542 Converging ring
69 0392881 Bushing assy, prop. sst
69 0386638 Bushing assy, prop. alum
70 0302497 Grommet, lower water tube
71 0395339 Water tube
72 0330658 Washer
73 0325625 Keeper, shift rod
74 0323943 Spacer
76 0328333 Screw
79 0311338 "o" ring,lever to cover
80 0301877 O ring shift rod
81 0554545 "o" ring, small
82 0328772 Plate, impeller housing
82 0328755 Plate, impeller housing
83 0331479 Pin, cam follower
0396707 0396707 Extension kit assy
0325541 0325541 Shift rod, upper
50 0328317 Drive shaft, long
53 0306470 Lock washer
54 0306422 Nut
58 0319785 Bushing
64 0326693 Spacer, imp. housing
71 0395340 Water tube washer
72 0330658 Washer
75 0392967 Extension, assy
76 0339823 Screw, gearcase to housing This part replaces 0327973.
77 0320173 Stud
78 0305283 . screw, extension 5" longer parts
79 0311338 "o" ring,lever to cover
0325975 0325975 Mount, rubber, lower
0325974 0325974 Mount, rubber, upper
84 0393630 Water pump repair kit includes impeller housing This part replaces 0393509.
84 0393630 Water pump repair kit includes impeller housing
85 0394415 Chrome cup plate kit
86 0396351 Gearcase seal kit
