Disclaimer: Please note that the items featured in the image (schematic diagram) are not sold as a bundled set. To facilitate your search, kindly refer to the schematic object key provided below in order to locate a specific item within the image.
Schematic Object Key : 4
Product Description: Washer, Magnet
Category: STERN DRIVE / 1998 / 5 / 50FBPBYC 1998 / LOWER GEARCASE -- DUAL PROP
Disclaimer: Each item listed in the table below is available for individual purchase and is not sold as part of a package or set.
Parts List:
| Key | Part No. | Product Name | Additional_info |
|---|---|---|---|
| 3855908 | 3855908 | Gearcase assy., 1.95, 16 30 | |
| 3855907 | 3855907 | Gearcase assy., 1.78, 17 29 | |
| 1 | 3855514 | Gearcase bearing | |
| 2 | 0184654 | Bearing, lower driveshaft | |
| 3 | 0854096 | Magnet | |
| 4 | 0955893 | Washer, magnet | |
| 5 | 3854898 | Seal, exhaust cover | |
| 6 | 3855504 | Screw, exhaust cover, rear | |
| 7 | 3855544 | Cover, exhaust | |
| 8 | 0309905 | Scew,cylinder head | This part replaces 3855578. |
| 9 | 3855819 | Screw, exhaust cover, front | |
| 10 | 3852866 | O ring, support housing | |
| 11 | 3855636 | Retainer, bearing | |
| 12 | 3854250 | Bearing, driveshaft, upper | |
| 13 | 3854249 | Bearing, driveshaft, lower | |
| 14 | 3852889 | Shim, pinion position, 0.003 in. | |
| 14 | 3852890 | Shim, pinion position, 0.004 in. | |
| 14 | 3852891 | Shim, pinion position, 0.005 in. | |
| 14 | 3852892 | Shim, pinion position, 0.010 in. | |
| 15 | 3855492 | Driveshaft, vertical | |
| 16 | 0184682 | Inner ring | |
| 17 | 3851309 | Gear set, 1.95, 16 30 | |
| 17 | 3851304 | Gear set, 1.78, 17 29 | |
| 18 | 0184683 | Race, bearing | |
| 19 | 0941885 | Nut, gear housing | |
| 20 | 0183272 | Bearing, outer propeller shaft | |
| 21 | 0853807 | Seal, rear inner prop shaft | |
| 22 | 0853808 | Seal, forward inner prop shaft | |
| 23 | 3855008 | Shim, inner gear, 0.002 in. | |
| 23 | 3855071 | Shim, inner gear, 0.003 in. | |
| 23 | 3855009 | Shim, inner gear, 0.004 in. | |
| 23 | 3855072 | Shim, inner gear, 0.005 in. | |
| 23 | 3855010 | Shim, inner gear, 0.006 in. | |
| 23 | 3855011 | Shim, inner gear, 0.008 in. | |
| 23 | 3855073 | Shim, inner gear, 0.010 in. | |
| 23 | 3855012 | Shim, inner gear, 0.016 in. | |
| 24 | 0184691 | Bearing, outer gear | |
| 25 | 3855796 | Shim, outer gear, 0.002 in. | |
| 25 | 3855797 | Shim, outer gear, 0.003 in. | |
| 25 | 3855798 | Shim, outer gear, 0.005 in. | |
| 25 | 3855799 | Shim, outer gear, 0.010 in. | |
| 26 | 3851205 | Propeller shaft, inner | |
| 27 | 3854482 | Bearing, inner propeller shaft gear | |
| 28 | 3851234 | Housing, propeller shaft | |
| 29 | 0184765 | Bearing, outer propeller shaft | |
| 30 | 3854625 | O ring, propeller shaft hsg. | |
| 31 | 0852212 | Nut, pinion gear | |
| 32 | 0183859 | Bearing, outer propeller shaft | |
| 33 | 0851407 | Seal, outer propeller shaft | |
| 34 | 3851329 | Screw, drain | |
| 35 | 0955981 | O ring, drain screw | |
| 36 | 0946438 | O ring, propeller shaft retainer | |
| 37 | 3851246 | Retainer, bearing housing | |
| 38 | 3851327 | Ring, retaining | |
| 39 | 3854624 | O ring, retaining ring | |
| 40 | 3852959 | O ring, oil passage | |
| 41 | 3852349 | Screw, gear housing | |
| 42 | 3852960 | Screw, gear housing | |
| 43 | 3854601 | Retainer, seal | |
| 44 | 3855411 | Anode, gearcase | |
| 45 | 0328724 | Screw | This part replaces 3852186. |
| 46 | 0328701 | Lockwasher, double ended bolt | This part replaces 3852182. |
| 47 | 3852268 | Driveshaft, intermediate | |
| 48 | 3854795 | Tube, water supply | |
| 49 | 3852315 | Seal, water supply tube | |
| 50 | 3854595 | Seal, water supply tube | |
| 51 | 3856002 | Gearcase seal kit |
